+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SLPX152M250H4P3CAP ALUM 1500UF 20% 250V SNAP |
5,338 | - |
|
Техническая |
Bulk | SLPX | Active | 1500 µF | ±20% | 250 V | 133mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.33 A @ 120 Hz | 6.37 A @ 20 kHz | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.772 (45.00mm) | - | Through Hole |
|
B43504A5337M000CAP ALUM 330UF 20% 450V SNAP |
3,037 | - |
|
Техническая |
Bulk | B43504 | Not For New Designs | 330 µF | ±20% | 450 V | 410mOhm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.6 A @ 100 Hz | - | 490 mOhms | 0.394 (10.00mm) | 1.181 Dia (30.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
ALC10C153EB035CAP ALUM 15000UF 20% 35V SNAP |
203 | - |
|
Техническая |
Box | ALC10 | Active | 15000 µF | ±20% | 35 V | 87mOhm @ 100Hz | 18000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.24 A @ 100 Hz | 4.31 A @ 10 kHz | 78 mOhms | 0.886 (22.50mm) | 1.575 Dia (40.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
383LX153M063A062CAP ALUM 15000UF 20% 63V SNAP |
814 | - |
|
Техническая |
Bulk | 383LX | Active | 15000 µF | ±20% | 63 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | - | 1.378 Dia (35.00mm) | 2.559 (65.00mm) | - | Through Hole |
|
MAL205657103E3CAP ALUM 10000UF 20% 40V SNAP |
3,059 | - |
|
Техническая |
Bulk | 056 PSM-SI | Active | 10000 µF | ±20% | 40 V | 38mOhm @ 100Hz | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 4.2 A @ 100 Hz | - | 28 mOhms | 0.394 (10.00mm) | 1.181 Dia (30.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
381LQ471M450A452CAP ALUM 470UF 20% 450V SNAP |
105 | - |
|
Техническая |
Bulk | 381LQ | Active | 470 µF | ±20% | 450 V | 388mOhm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.74 A @ 120 Hz | 2.44 A @ 20 kHz | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.850 (47.00mm) | - | Through Hole |
|
ALT22A153DE063CAP ALUM 15000UF 20% 63V SNAP |
609 | - |
|
Техническая |
Box | ALT22 | Active | 15000 µF | ±20% | 63 V | - | - | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.394 (10.00mm) | 1.575 Dia (40.00mm) | 3.031 (77.00mm) | - | Through Hole |
|
ALA7DA471DE500CAP ALUM 470UF 20% 500V SNAP |
129 | - |
|
Техническая |
Bulk | ALA7D | Active | 470 µF | ±20% | 500 V | 532.2mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 2.03 A @ 100 Hz | 4.42 A @ 10 kHz | 250.4 mOhms | - | 1.378 Dia (35.00mm) | 1.850 (47.00mm) | - | Through Hole |
|
380LQ272M200A052CAP ALUM 2700UF 20% 200V SNAP |
10,055 | - |
|
Техническая |
Bulk | 380LQ | Active | 2700 µF | ±20% | 200 V | 105mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 5 A @ 120 Hz | 7 A @ 20 kHz | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
380LX473M035A082CAP ALUM 47000UF 20% 35V SNAP |
1,673 | - |
|
Техническая |
Bulk | 380LX | Active | 47000 µF | ±20% | 35 V | 15mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 9.5 A @ 120 Hz | - | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 3.228 (82.00mm) | - | Through Hole |
|
ALC10C331ED450CAP ALUM 330UF 20% 450V SNAP |
519 | - |
|
Техническая |
Bulk | ALC10 | Active | 330 µF | ±20% | 450 V | 348mOhm @ 100Hz | 18000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.47 A @ 100 Hz | 4.91 A @ 10 kHz | 210 mOhms | 0.886 (22.50mm) | 1.575 Dia (40.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
ELHS451VSN821MA60SCAP ALUM 820UF 20% 450V SNAP |
918 | - |
|
Техническая |
Bulk | LHS | Active | 820 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.52 A @ 120 Hz | 3.6036 A @ 50 kHz | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 2.461 (62.50mm) | - | Through Hole |
|
SLP681M400H4P3CAP ALUM 680UF 20% 400V SNAP |
5,191 | - |
|
Техническая |
Bulk | SLP0712TE (750W) | Active | 680 µF | ±20% | 400 V | 488mOhm | 3000 Hrs @ 105°C | -25°C ~ 105°C | - | - | General Purpose | - | - | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.772 (45.00mm) | - | Through Hole |
|
B41458B7100M000CAP ALUM 100000UF 20% 40V SCREW |
773 | - |
|
Техническая |
Bulk | B41458 | Active | 100000 µF | ±20% | 40 V | 8.2mOhm @ 100Hz | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 19 A @ 100 Hz | - | 7 mOhms | 1.122 (28.50mm) | 2.532 Dia (64.30mm) | 4.201 (106.70mm) | - | Chassis Mount |
|
|
ALA8DA431DF500CAP ALUM 430UF 20% 500V SNAP |
1,000 | - |
|
Техническая |
Bulk | ALA8D | Active | 430 µF | ±20% | 500 V | 484mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 2.7 A @ 100 Hz | 6.1 A @ 10 kHz | 358 mOhms | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
PEH534YDG3470M2CAP ALUM 470UF 20% 450V SNAP |
796 | - |
|
Техническая |
Bulk | PEH534 | Active | 470 µF | ±20% | 450 V | 180mOhm @ 100Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.9 A @ 100 Hz | - | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.969 (50.00mm) | - | Through Hole |
|
382LX103M100A082CAP ALUM 10000UF 20% 100V SNAP |
1,198 | - |
|
Техническая |
Bulk | 382LX | Active | 10000 µF | ±20% | 100 V | - | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | - | 1.378 Dia (35.00mm) | 3.228 (82.00mm) | - | Through Hole |
|
ALC70A102EH450CAP ALUM 1000UF 20% 450V SNAP |
853 | - |
|
Техническая |
Bulk | ALC70 | Active | 1000 µF | ±20% | 450 V | 148mOhm @ 100Hz | 18000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.11 A @ 100 Hz | 8.53 A @ 10 kHz | 85 mOhms | 0.394 (10.00mm) | 1.575 Dia (40.00mm) | 2.441 (62.00mm) | - | Through Hole |
|
383LX222M250N062CAP ALUM 2200UF 20% 250V SNAP |
886 | - |
|
Техническая |
Bulk | 383LX | Active | 2200 µF | ±20% | 250 V | 98mOhm | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.7 A @ 120 Hz | 5.15 A @ 20 kHz | - | - | 1.575 Dia (40.00mm) | 2.559 (65.00mm) | - | Through Hole |
|
DCMC763U100DF2BCAP ALUM 76000UF 100V SCREW |
152 | - |
|
Техническая |
Bulk | DCMC | Active | 76000 µF | -10%, +75% | 100 V | 11.2mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 21.3 A @ 120 Hz | 22.365 A @ 10 kHz | - | 1.250 (31.75mm) | 3.000 Dia (76.20mm) | 5.687 (144.45mm) | - | Chassis Mount |
