+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEV-HA1J330PCAP ALUM 33UF 20% 63V SMD |
2,371 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Obsolete | 33 µF | ±20% | 63 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 45 mA @ 120 Hz | - | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEV-FC1E101PCAP ALUM 100UF 20% 25V SMD |
2,149 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 100 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 337.5 mA @ 120 Hz | 450 mA @ 100 kHz | 300 mOhms | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEV-FC1H101PCAP ALUM 100UF 20% 50V SMD |
3,632 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 100 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 375 mA @ 120 Hz | 500 mA @ 100 kHz | 300 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC1H470PCAP ALUM 47UF 20% 50V SMD |
3,711 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 47 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 375 mA @ 120 Hz | 500 mA @ 100 kHz | 300 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC1H330PCAP ALUM 33UF 20% 50V SMD |
3,662 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 33 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 225 mA @ 120 Hz | 300 mA @ 100 kHz | 600 mOhms | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEV-FC1V331PCAP ALUM 330UF 20% 35V SMD |
3,176 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 330 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC1V221PCAP ALUM 220UF 20% 35V SMD |
2,892 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 220 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC1E471PCAP ALUM 470UF 20% 25V SMD |
2,935 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 470 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC1E331PCAP ALUM 330UF 20% 25V SMD |
4,000 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 330 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC1C471PCAP ALUM 470UF 20% 16V SMD |
3,192 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 470 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-HA1J470PCAP ALUM 47UF 20% 63V SMD |
3,962 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Obsolete | 47 µF | ±20% | 63 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 50 mA @ 120 Hz | - | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC1A102PCAP ALUM 1000UF 20% 10V SMD |
2,232 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 1000 µF | ±20% | 10 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC0J152PCAP ALUM 1500UF 20% 6.3V SMD |
3,277 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 1500 µF | ±20% | 6.3 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-FC0J102PCAP ALUM 1000UF 20% 6.3V SMD |
3,686 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 1000 µF | ±20% | 6.3 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 502.5 mA @ 120 Hz | 670 mA @ 100 kHz | 150 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-HA2A330PCAP ALUM 33UF 20% 100V SMD |
2,602 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Obsolete | 33 µF | ±20% | 100 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 65 mA @ 120 Hz | - | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEV-HA2A220PCAP ALUM 22UF 20% 100V SMD |
3,949 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Obsolete | 22 µF | ±20% | 100 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 60 mA @ 120 Hz | - | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEV-HA2A100PCAP ALUM 10UF 20% 100V SMD |
3,942 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Obsolete | 10 µF | ±20% | 100 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 55 mA @ 120 Hz | - | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEV-HA2A4R7PCAP ALUM 4.7UF 20% 100V SMD |
3,860 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Obsolete | 4.7 µF | ±20% | 100 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 50 mA @ 120 Hz | - | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEV-HA1C331UPCAP ALUM 330UF 20% 16V SMD |
3,474 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Obsolete | 330 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 170 mA @ 120 Hz | - | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEV-FC1H221PCAP ALUM 220UF 20% 50V SMD |
3,791 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Obsolete | 220 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 375 mA @ 120 Hz | 500 mA @ 100 kHz | 300 mOhms | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
