+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-TP1E221AVCAP ALUM 220UF 20% 25V SMD |
470 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | TP, Anti-Vibration | Active | 220 µF | ±20% | 25 V | 150mOhm @ 100kHz | 3000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 325 mA @ 120 Hz | 500 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEU-FS0J822SBCAP ALUM 8200UF 20% 6.3V RADIAL |
978 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 8200 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.64 A @ 120 Hz | 3.3 A @ 100 kHz | 17 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
EEU-FS1A562SBCAP ALUM 5600UF 20% 10V RADIAL |
797 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 5600 µF | ±20% | 10 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.64 A @ 120 Hz | 3.3 A @ 100 kHz | 17 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
EEU-FS0J752SBCAP ALUM 7500UF 20% 6.3V RADIAL |
475 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 7500 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.64 A @ 120 Hz | 3.3 A @ 100 kHz | 17 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
EEU-FS1A822BCAP ALUM 8200UF 20% 10V RADIAL |
919 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 8200 µF | ±20% | 10 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.056 A @ 120 Hz | 3.82 A @ 100 kHz | 14 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.457 (37.00mm) | - | Through Hole |
|
EEE-FK1A242SVCAP ALUM 2400UF 20% 10V SMD |
960 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS, Anti-Vibration | Active | 2400 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 825 mA @ 120 Hz | 1.1 A @ 100 kHz | - | - | 0.492 Dia (12.50mm) | 0.551 (14.00mm) | 0.531 L x 0.531 W (13.50mm x 13.50mm) | Surface Mount |
|
EEU-EB2C680SCAP ALUM 68UF 20% 160V RADIAL |
236 | - |
|
Техническая |
Bulk | EB-A | Active | 68 µF | ±20% | 160 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 412.5 mA @ 120 Hz | 750 mA @ 100 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
EEE-FK0J752SMCAP ALUM 7500UF 20% 6.3V SMD |
387 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 7500 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.35 A @ 120 Hz | 1.8 A @ 100 kHz | - | - | 0.630 Dia (16.00mm) | 0.669 (17.00mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
|
|
EEE-FK1A562SMCAP ALUM 5600UF 20% 10V SMD |
418 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 5600 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.35 A @ 120 Hz | 1.8 A @ 100 kHz | - | - | 0.630 L (16.00mm) | 0.669 (17.00mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
|
EEU-FS0J562CAP ALUM 5600UF 20% 6.3V RADIAL |
118 | - |
|
Техническая |
Bulk | FS-A | Active | 5600 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.552 A @ 120 Hz | 3.19 A @ 100 kHz | 15 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.063 (27.00mm) | - | Through Hole |
|
EEU-FC0J682LCAP ALUM 6800UF 20% 6.3V RADIAL |
173 | - |
|
Техническая |
Bulk | FC | Active | 6800 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 2.257 A @ 120 Hz | 2.655 A @ 100 kHz | 18 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.575 (40.00mm) | - | Through Hole |
|
|
EEE-FK0J103SMCAP ALUM 10000UF 20% 6.3V SMD |
470 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 10000 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.545 A @ 120 Hz | 2.06 A @ 100 kHz | - | - | 0.709 Dia (18.00mm) | 0.669 (17.00mm) | 0.748 L x 0.748 W (19.00mm x 19.00mm) | Surface Mount |
|
|
EEE-FK1A752SMCAP ALUM 7500UF 20% 10V SMD |
181 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 7500 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.545 A @ 120 Hz | 2.06 A @ 100 kHz | - | - | 0.709 Dia (18.00mm) | 0.669 (17.00mm) | 0.748 L x 0.748 W (19.00mm x 19.00mm) | Surface Mount |
|
|
EEE-FK1C562SMCAP ALUM 5600UF 20% 16V SMD |
133 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS | Active | 5600 µF | ±20% | 16 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.545 A @ 120 Hz | 2.06 A @ 100 kHz | - | - | 0.709 Dia (18.00mm) | 0.669 (17.00mm) | 0.748 L x 0.748 W (19.00mm x 19.00mm) | Surface Mount |
|
EEU-FS0J752LCAP ALUM 7500UF 20% 6.3V RADIAL |
990 | - |
|
Техническая |
Bulk | FS-A | Active | 7500 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3 A @ 120 Hz | 3.75 A @ 100 kHz | 12 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.457 (37.00mm) | - | Through Hole |
|
|
EEU-FS0J822LCAP ALUM 8200UF 20% 6.3V RADIAL |
180 | - |
|
Техническая |
Bulk | FS-A | Active | 8200 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3 A @ 120 Hz | 3.75 A @ 100 kHz | 12 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.457 (37.00mm) | - | Through Hole |
|
EEU-FS0J622LCAP ALUM 6200UF 20% 6.3V RADIAL |
998 | - |
|
Техническая |
Bulk | FS-A | Active | 6200 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.904 A @ 120 Hz | 3.63 A @ 100 kHz | 13 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
EEU-FS1A512LCAP ALUM 5100UF 20% 10V RADIAL |
952 | - |
|
Техническая |
Bulk | FS-A | Active | 5100 µF | ±20% | 10 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.904 A @ 120 Hz | 3.63 A @ 100 kHz | 13 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
EEU-FS0J682LCAP ALUM 6800UF 20% 6.3V RADIAL |
899 | - |
|
Техническая |
Bulk | FS-A | Active | 6800 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.904 A @ 120 Hz | 3.63 A @ 100 kHz | 13 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
EEE-FK0J752SVCAP ALUM 7500UF 20% 6.3V SMD |
470 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS, Anti-Vibration | Active | 7500 µF | ±20% | 6.3 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.35 A @ 120 Hz | 1.8 A @ 100 kHz | - | - | 0.630 Dia (16.00mm) | 0.669 (17.00mm) | 0.669 L x 0.669 W (17.00mm x 17.00mm) | Surface Mount |
