+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL213290505E3CAP ALUM 47UF 100V AXIAL |
2,316 | - |
|
Техническая |
Tape & Reel (TR) | 132 ALL-DIN | Active | 47 µF | -10%, +50% | 100 V | 2Ohm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 220 mA @ 100 Hz | - | 900 mOhms | - | 0.394 Dia x 0.984 L (10.00mm x 25.00mm) | - | - | Through Hole |
|
|
MAL213290507E3CAP ALUM 470UF 16V AXIAL |
3,653 | - |
|
Техническая |
Tape & Reel (TR) | 132 ALL-DIN | Active | 470 µF | -10%, +50% | 16 V | 470mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 450 mA @ 100 Hz | - | 260 mOhms | - | 0.394 Dia x 0.984 L (10.00mm x 25.00mm) | - | - | Through Hole |
|
|
MAL213290508E3CAP ALUM 330UF 16V AXIAL |
3,319 | - |
|
Техническая |
Tape & Reel (TR) | 132 ALL-DIN | Active | 330 µF | -10%, +50% | 16 V | 670mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 320 mA @ 100 Hz | - | 360 mOhms | - | 0.394 Dia x 0.984 L (10.00mm x 25.00mm) | - | - | Through Hole |
|
|
MAL213290511E3CAP ALUM 150UF 40V AXIAL |
3,634 | - |
|
Техническая |
Tape & Reel (TR) | 132 ALL-DIN | Active | 150 µF | -10%, +50% | 40 V | 950mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 310 mA @ 100 Hz | - | 500 mOhms | - | 0.394 Dia x 0.984 L (10.00mm x 25.00mm) | - | - | Through Hole |
|
MAL215051122E3CAP ALUM 1200UF 20% 50V RADIAL |
2,166 | - |
|
Техническая |
Bulk | 150 RMI | Active | 1200 µF | ±20% | 50 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.672 A @ 100 Hz | - | 27 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole |
|
MAL216099106E3CAP ALUM 680UF 20% 50V SMD |
3,604 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | 160 CLA | Active | 680 µF | ±20% | 50 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive | - | 800 mA @ 100 kHz | 52 mOhms | - | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | 0.654 L x 0.654 W (16.60mm x 16.60mm) | Surface Mount |
|
MAL213825222E3CAP ALUM 2200UF 20% 16V AXIAL |
2,232 | - |
|
Техническая |
Tape & Reel (TR) | 138 AML | Active | 2200 µF | ±20% | 16 V | 170mOhm @ 100kHz | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | Automotive | 1.09 A @ 100 Hz | - | 150 mOhms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole |
|
|
MAL216099505E3CAP ALUM 2200UF 20% 16V SMD |
3,106 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | 160 CLA | Active | 2200 µF | ±20% | 16 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive | - | 1.1 A @ 100 kHz | 35 mOhms | - | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | 0.654 L x 0.654 W (16.60mm x 16.60mm) | Surface Mount |
|
|
MAL216099005E3CAP ALUM 1000UF 20% 35V SMD |
2,347 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | 160 CLA | Active | 1000 µF | ±20% | 35 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive | - | 1 A @ 100 kHz | 35 mOhms | - | 0.630 Dia (16.00mm) | 0.866 (22.00mm) | 0.654 L x 0.654 W (16.60mm x 16.60mm) | Surface Mount |
|
MAL225061152E3CAP ALUM 1500UF 20% 50V RADIAL |
3,726 | - |
|
Техническая |
Box | 250 RMI-V | Active | 1500 µF | ±20% | 50 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Audio, Automotive | 1.672 A @ 100 Hz | 2.2 A @ 100 kHz | 27 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.476 (37.50mm) | - | Through Hole |
|
|
MAL225064682E3CAP ALUM 6800UF 20% 10V RADIAL |
2,597 | - |
|
Техническая |
Box | 250 RMI-V | Active | 6800 µF | ±20% | 10 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Audio, Automotive | 2.196 A @ 100 Hz | 2.89 A @ 100 kHz | 19 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole |
|
|
MAL225060222E3CAP ALUM 2200UF 20% 35V RADIAL |
3,805 | - |
|
Техническая |
Box | 250 RMI-V | Active | 2200 µF | ±20% | 35 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Audio, Automotive | 2.196 A @ 100 Hz | 2.89 A @ 100 kHz | 19 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
MAL225065472E3CAP ALUM 4700UF 20% 16V RADIAL |
3,238 | - |
|
Техническая |
Box | 250 RMI-V | Active | 4700 µF | ±20% | 16 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Audio, Automotive | 2.196 A @ 100 Hz | 2.89 A @ 100 kHz | 19 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
MAL225068102E3CAP ALUM 1000UF 20% 63V RADIAL |
2,772 | - |
|
Техническая |
Box | 250 RMI-V | Active | 1000 µF | ±20% | 63 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Audio, Automotive | 1.444 A @ 100 Hz | 1.9 A @ 100 kHz | 42 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.319 (33.50mm) | - | Through Hole |
|
|
MAL225066332E3CAP ALUM 3300UF 20% 25V RADIAL |
2,146 | - |
|
Техническая |
Box | 250 RMI-V | Active | 3300 µF | ±20% | 25 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Audio, Automotive | 2.196 A @ 100 Hz | 2.89 A @ 100 kHz | 19 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole |
|
|
MAL215256479E3CAP ALUM 47UF 20% 400V RADIAL |
2,414 | - |
|
Техническая |
Bulk | 152 RMH | Active | 47 µF | ±20% | 400 V | - | 4000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 240 mA @ 100 Hz | - | 2 Ohms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
MAL213694565E3CAP ALUM 5600UF 20% 10V RADIAL |
3,767 | - |
|
Техническая |
Bulk | 136 RVI | Active | 5600 µF | ±20% | 10 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.884 A @ 100 Hz | - | 25 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
MAL213698685E3CAP ALUM 680UF 20% 63V RADIAL |
3,719 | - |
|
Техническая |
Bulk | 136 RVI | Active | 680 µF | ±20% | 63 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 735 mA @ 100 Hz | - | 54 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
MAL225919399E3CAP ALUM 39UF 20% 500V SNAP |
3,293 | - |
|
Box | 259 PHM-SI | Active | 39 µF | ±20% | 500 V | 3.31Ohm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 530 mA @ 100 Hz | 795 mA @ 10 kHz | 2.44 Ohms | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.063 (27.00mm) | - | Through Hole | |
|
|
MAL225959399E3CAP ALUM 39UF 20% 500V SNAP |
3,307 | - |
|
Box | 259 PHM-SI | Active | 39 µF | ±20% | 500 V | 3.31Ohm @ 100Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 530 mA @ 100 Hz | 795 mA @ 10 kHz | 2.44 Ohms | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.063 (27.00mm) | - | Through Hole |
