| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL226066102E3CAP ALUM 1000UF 20% 25V RADIAL |
2,599 | - |
|
Box | 260 RLA-V | Active | 1000 µF | ±20% | 25 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 700 mA @ 100 Hz | 1 A @ 100 kHz | 27 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole | |
|
MAL224698686E3CAP ALUM 680UF 20% 63V RADIAL |
3,491 | - |
|
Box | 246 RTI-V | Active | 680 µF | ±20% | 63 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | 1.1 A @ 100 Hz | 2.2 A @ 100 kHz | 36 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole | |
|
|
MAL226060681E3CAP ALUM 680UF 20% 35V RADIAL |
3,661 | - |
|
Box | 260 RLA-V | Active | 680 µF | ±20% | 35 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 650 mA @ 100 Hz | 1 A @ 100 kHz | 27 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole | |
|
|
MAL224666332E3CAP ALUM 3300UF 20% 25V RADIAL |
3,830 | - |
|
Box | 246 RTI-V | Active | 3300 µF | ±20% | 25 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | 2.1 A @ 100 Hz | 3 A @ 100 kHz | 21 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole | |
|
MAL215090185E3CAP ALUM 330UF 20% 100V RADIAL |
2,577 | - |
|
Техническая |
Bulk | 150 RMI | Active | 330 µF | ±20% | 100 V | - | 7000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 1.292 A @ 100 Hz | - | 74 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
MAL212627821E3CAP ALUM 820UF 20% 40V AXIAL |
3,399 | - |
|
Box | 126 ALX | Active | 820 µF | ±20% | 40 V | 141mOhm @ 100Hz | 8000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | Automotive | 970 mA @ 100 Hz | 1.261 A @ 10 kHz | 55 mOhms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole | |
|
|
MAL212628471E3CAP ALUM 470UF 20% 63V AXIAL |
3,493 | - |
|
Box | 126 ALX | Active | 470 µF | ±20% | 63 V | 179mOhm @ 100Hz | 8000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | Automotive | 860 mA @ 100 Hz | 1.118 A @ 10 kHz | 91 mOhms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole | |
|
MAL212624392E3CAP ALUM 3900UF 20% 10V AXIAL |
3,271 | - |
|
Box | 126 ALX | Active | 3900 µF | ±20% | 10 V | 97mOhm @ 100Hz | 8000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | Automotive | 1.14 A @ 100 Hz | 1.368 A @ 10 kHz | 46 mOhms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole | |
|
|
MAL212626182E3CAP ALUM 1800UF 20% 25V AXIAL |
3,877 | - |
|
Box | 126 ALX | Active | 1800 µF | ±20% | 25 V | 117mOhm @ 100Hz | 8000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | Automotive | 1.02 A @ 100 Hz | 1.224 A @ 10 kHz | 46 mOhms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole | |
|
|
MAL212625272E3CAP ALUM 2700UF 20% 16V AXIAL |
3,569 | - |
|
Box | 126 ALX | Active | 2700 µF | ±20% | 16 V | 93mOhm @ 100Hz | 8000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | Automotive | 1.09 A @ 100 Hz | 1.308 A @ 10 kHz | 46 mOhms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole | |
|
MAL203860332E3CAP ALUM 3300UF 20% 35V RADIAL |
3,800 | - |
|
Техническая |
Bulk | 038 RSU | Last Time Buy | 3300 µF | ±20% | 35 V | - | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.275 A @ 100 Hz | - | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.476 (37.50mm) | - | Through Hole |
|
MAL216065152E3CAP ALUM 1500UF 20% 16V RADIAL |
2,365 | - |
|
Техническая |
Bulk | 160 RLA | Active | 1500 µF | ±20% | 16 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive | - | - | 35 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
MAL216060471E3CAP ALUM 470UF 20% 35V RADIAL |
3,961 | - |
|
Техническая |
Bulk | 160 RLA | Active | 470 µF | ±20% | 35 V | - | 2000 Hrs @ 150°C | -55°C ~ 150°C | Polar | AEC-Q200 | Automotive | - | - | 35 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
MAL224695476E3CAP ALUM 4700UF 20% 16V RADIAL |
3,682 | - |
|
Box | 246 RTI-V | Active | 4700 µF | ±20% | 16 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | 2.1 A @ 100 Hz | 3 A @ 100 kHz | 21 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole | |
|
|
MAL224691126E3CAP ALUM 1200UF 20% 50V RADIAL |
3,393 | - |
|
Box | 246 RTI-V | Active | 1200 µF | ±20% | 50 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | 1.275 A @ 100 Hz | 2.55 A @ 100 kHz | 27 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole | |
|
MAL224690226E3CAP ALUM 2200UF 20% 35V RADIAL |
3,919 | - |
|
Box | 246 RTI-V | Active | 2200 µF | ±20% | 35 V | - | 6000 Hrs @ 125°C | -55°C ~ 125°C | Polar | AEC-Q200 | Automotive | 1.95 A @ 100 Hz | 3 A @ 100 kHz | 21 mOhms | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.319 (33.50mm) | - | Through Hole | |
|
MAL204281688E3CAP ALUM 6.8UF 450V AXIAL |
3,417 | - |
|
Техническая |
Tape & Box (TB) | 042 AMH-ELB | Active | 6.8 µF | -10%, +50% | 450 V | 8.3Ohm @ 100Hz | 20000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 162 mA @ 100 Hz | - | 4.8 Ohms | - | 0.492 Dia x 1.181 L (12.50mm x 30.00mm) | - | - | Through Hole |
|
|
MAL204282688E3CAP ALUM 6.8UF 450V AXIAL |
3,329 | - |
|
Техническая |
Tape & Box (TB) | 042 AMH-ELB | Active | 6.8 µF | -10%, +50% | 450 V | 8.3Ohm @ 100Hz | 20000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 162 mA @ 100 Hz | - | 4.8 Ohms | - | 0.492 Dia x 1.181 L (12.50mm x 30.00mm) | - | - | Through Hole |
|
MAL211814332E3CAP ALUM 3300UF 20% 10V AXIAL |
2,391 | - |
|
Техническая |
Bulk | 118 AHT | Active | 3300 µF | ±20% | 10 V | 190mOhm | 8000 Hrs @ 125°C | -55°C ~ 125°C | Polar | - | Automotive | - | 1.284 A @ 10 kHz | 180 mOhms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole |
|
MAL204223339E3CAP ALUM 33UF 250V AXIAL |
2,586 | - |
|
Техническая |
Tape & Box (TB) | 042 ASH | Active | 33 µF | -10%, +50% | 250 V | 4.5Ohm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 290 mA @ 100 Hz | - | 3.4 Ohms | - | 0.591 Dia x 1.181 L (15.00mm x 30.00mm) | - | - | Through Hole |
