+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AVS336M63F24B-FCAP ALUM 33UF 20% 63V SMD |
2,955 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 33 µF | ±20% | 63 V | 9.1Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 45 mA @ 120 Hz | 76.5 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
AVS337M06E16B-FCAP ALUM 330UF 20% 6.3V SMD |
3,053 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 330 µF | ±20% | 6.3 V | 1.8Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 300 mA @ 120 Hz | 510 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
AVS337M06X16B-FCAP ALUM 330UF 20% 6.3V SMD |
2,398 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 330 µF | ±20% | 6.3 V | 1.3Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 150 mA @ 120 Hz | 255 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.311 (7.90mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
AVS337M10F24B-FCAP ALUM 330UF 20% 10V SMD |
2,830 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 330 µF | ±20% | 10 V | 1.3Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 330 mA @ 120 Hz | 561 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
AVS337M16F24B-FCAP ALUM 330UF 20% 16V SMD |
2,959 | - |
|
Техническая |
Bulk | AVS | Obsolete | 330 µF | ±20% | 16 V | 1Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 320 mA @ 120 Hz | 544 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
AVS337M16G24B-FCAP ALUM 330UF 20% 16V SMD |
2,302 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 330 µF | ±20% | 16 V | 1Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 380 mA @ 120 Hz | 646 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
AVS337M25F24B-FCAP ALUM 330UF 20% 25V SMD |
2,634 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 330 µF | ±20% | 25 V | 800mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 150 mA @ 120 Hz | 255 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
AVS337M25G24B-FCAP ALUM 330UF 20% 25V SMD |
2,263 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 330 µF | ±20% | 25 V | 800mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 340 mA @ 120 Hz | 578 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
AVS337M35G24B-FCAP ALUM 330UF 20% 35V SMD |
3,415 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 330 µF | ±20% | 35 V | 700mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 320 mA @ 120 Hz | 544 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
AVS474M50A12B-FCAP ALUM 0.47UF 20% 50V SMD |
2,285 | - |
|
Техническая |
Bulk | AVS | Obsolete | 0.47 µF | ±20% | 50 V | 494Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 5 mA @ 120 Hz | 8.5 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
|
AVS474M50A12T-FCAP ALUM 0.47UF 20% 50V SMD |
3,182 | - |
|
Техническая |
Tape & Reel (TR) | AVS | Obsolete | 0.47 µF | ±20% | 50 V | 494Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 5 mA @ 120 Hz | 8.5 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
AVS474M50B12B-FCAP ALUM 0.47UF 20% 50V SMD |
3,054 | - |
|
Техническая |
Bulk | AVS | Obsolete | 0.47 µF | ±20% | 50 V | 424Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 5 mA @ 120 Hz | 8.5 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
AVS474M50B12T-FCAP ALUM 0.47UF 20% 50V SMD |
3,724 | - |
|
Техническая |
Tape & Reel (TR) | AVS | Obsolete | 0.47 µF | ±20% | 50 V | 424Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 5 mA @ 120 Hz | 8.5 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
AVS475M25A12B-FCAP ALUM 4.7UF 20% 25V SMD |
3,458 | - |
|
Техническая |
Bulk | AVS | Obsolete | 4.7 µF | ±20% | 25 V | 56.5Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 12 mA @ 120 Hz | 20.4 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
|
AVS475M25A12T-FCAP ALUM 4.7UF 20% 25V SMD |
2,117 | - |
|
Техническая |
Tape & Reel (TR) | AVS | Obsolete | 4.7 µF | ±20% | 25 V | 56.5Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 12 mA @ 120 Hz | 20.4 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
|
AVS475M25B12B-FCAP ALUM 4.7UF 20% 25V SMD |
2,210 | - |
|
Техническая |
Bulk | AVS | Discontinued at Mosen | 4.7 µF | ±20% | 25 V | 49.4Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 22 mA @ 120 Hz | 37.4 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
AVS475M2AE16B-FCAP ALUM 4.7UF 20% 100V SMD |
2,701 | - |
|
Техническая |
Bulk | AVS | Obsolete | 4.7 µF | ±20% | 100 V | 63.5Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 50 mA @ 120 Hz | 85 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
AVS475M2AE16T-FCAP ALUM 4.7UF 20% 100V SMD |
2,876 | - |
|
Техническая |
Tape & Reel (TR) | AVS | Obsolete | 4.7 µF | ±20% | 100 V | 63.5Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 50 mA @ 120 Hz | 85 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
AVS475M2AF24B-FCAP ALUM 4.7UF 20% 100V SMD |
2,276 | - |
|
Техническая |
Bulk | AVS | Obsolete | 4.7 µF | ±20% | 100 V | 63.5Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 80 mA @ 120 Hz | 136 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
AVS475M2AF24T-FCAP ALUM 4.7UF 20% 100V SMD |
2,751 | - |
|
Техническая |
Tape & Reel (TR) | AVS | Obsolete | 4.7 µF | ±20% | 100 V | 63.5Ohm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 80 mA @ 120 Hz | 136 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
