+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
UCD1K471MNQ1MSCAP ALUM 470UF 20% 80V SMD |
4,984 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | UCD | Not For New Designs | 470 µF | ±20% | 80 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 458.5 mA @ 120 Hz | 917 mA @ 100 kHz | 150 mOhms | - | 0.709 Dia (18.00mm) | 0.689 (17.50mm) | 0.752 L x 0.752 W (19.10mm x 19.10mm) | Surface Mount |
|
UHW1J122MHD6TNCAP ALUM 1200UF 20% 63V RADIAL |
500 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | UHW | Not For New Designs | 1200 µF | ±20% | 63 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.758 A @ 120 Hz | 2.93 A @ 100 kHz | 38 mOhms | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
UBX1H221MPLCAP ALUM 220UF 20% 50V RADIAL |
4,317 | - |
|
Техническая |
Bulk | UBX | Active | 220 µF | ±20% | 50 V | - | 1000 Hrs @ 150°C | -55°C ~ 150°C | Polar | - | Automotive | 320 mA @ 120 Hz | - | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.846 (21.50mm) | - | Through Hole |
|
LGU1V682MELZCAP ALUM 6800UF 20% 35V SNAP |
1,456 | - |
|
Техническая |
Bulk | LGU | Active | 6800 µF | ±20% | 35 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.41 A @ 120 Hz | 2.7715 A @ 50 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
URZ2G470MRD6CAP ALUM 47UF 20% 400V RADIAL |
147 | - |
|
Техническая |
Bulk | URZ | Active | 47 µF | ±20% | 400 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 300 mA @ 120 Hz | 480 mA @ 10 kHz | - | 0.394 (10.00mm) | 0.787 Dia (20.00mm) | 0.866 (22.00mm) | - | Through Hole |
|
LGU1H272MELZCAP ALUM 2700UF 20% 50V SNAP |
1,748 | - |
|
Техническая |
Bulk | LGU | Active | 2700 µF | ±20% | 50 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.7 A @ 120 Hz | 1.955 A @ 50 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
UCY2D121MHD6CAP ALUM 120UF 20% 200V RADIAL |
4,556 | - |
|
Техническая |
Bulk | UCY | Active | 120 µF | ±20% | 200 V | - | 12000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 810 mA @ 120 Hz | 1.62 A @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.299 (33.00mm) | - | Through Hole |
|
UBC1V102MNS1MSCAP ALUM 1000UF 20% 35V SMD |
917 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | UBC | Not For New Designs | 1000 µF | ±20% | 35 V | - | 1000 Hrs @ 150°C | -55°C ~ 150°C | Polar | - | Automotive | 770.5 mA @ 120 Hz | 1.15 A @ 100 kHz | - | - | 0.709 Dia (18.00mm) | 0.886 (22.50mm) | 0.752 L x 0.752 W (19.10mm x 19.10mm) | Surface Mount |
|
UHW2A391MHDCAP ALUM 390UF 20% 100V RADIAL |
2,800 | - |
|
Техническая |
Bulk | UHW | Not For New Designs | 390 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.3 A @ 120 Hz | 2.6 A @ 100 kHz | 38 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.476 (37.50mm) | - | Through Hole |
|
UVP1J471MHDCAP ALUM 470UF 20% 63V RADIAL |
1,683 | - |
|
Техническая |
Bulk | UVP | Not For New Designs | 470 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | 965 mA @ 120 Hz | 1.4475 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.476 (37.50mm) | - | Through Hole |
|
UCX1V182MNQ1MSCAP ALUM 1800UF 20% 35V SMD |
150 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | UCX | Not For New Designs | 1800 µF | ±20% | 35 V | 35mOhm | 2000 Hrs @ 135°C | -40°C ~ 135°C | Polar | - | General Purpose | 1.1 A @ 120 Hz | 2.2 A @ 100 kHz | - | - | 0.709 Dia (18.00mm) | 0.886 (22.50mm) | 0.752 L x 0.752 W (19.10mm x 19.10mm) | Surface Mount |
|
UCX1V222MNS1MSCAP ALUM 2200UF 20% 35V SMD |
190 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | UCX | Not For New Designs | 2200 µF | ±20% | 35 V | 35mOhm | 2000 Hrs @ 135°C | -40°C ~ 135°C | Polar | - | General Purpose | 1.1 A @ 120 Hz | 2.2 A @ 100 kHz | - | - | 0.709 Dia (18.00mm) | 0.866 (22.00mm) | 0.752 L x 0.752 W (19.10mm x 19.10mm) | Surface Mount |
|
LGU1J222MELZCAP ALUM 2200UF 20% 63V SNAP |
1,504 | - |
|
Техническая |
Bulk | LGU | Active | 2200 µF | ±20% | 63 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.82 A @ 120 Hz | 2.093 A @ 50 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.457 (37.00mm) | - | Through Hole |
|
LGN2C561MELZ30CAP ALUM 560UF 20% 160V SNAP |
316 | - |
|
Техническая |
Bulk | LGN | Active | 560 µF | ±20% | 160 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.5 A @ 120 Hz | 2.25 A @ 50 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
LLS1J332MELZCAP ALUM 3300UF 20% 63V SNAP |
184 | - |
|
Техническая |
Bulk | LLS | Active | 3300 µF | ±20% | 63 V | - | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.72 A @ 120 Hz | 3.128 A @ 50 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.457 (37.00mm) | - | Through Hole |
|
LGN2D271MELY25CAP ALUM 270UF 20% 200V SNAP |
146 | - |
|
Техническая |
Bulk | LGN | Active | 270 µF | ±20% | 200 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 990 mA @ 120 Hz | 1.485 A @ 50 kHz | - | 0.394 (10.00mm) | 0.787 Dia (20.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
LLS1H472MELZCAP ALUM 4700UF 20% 50V SNAP |
1,753 | - |
|
Техническая |
Bulk | LLS | Active | 4700 µF | ±20% | 50 V | - | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.02 A @ 120 Hz | 3.473 A @ 50 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
LGN2V121MELZ25CAP ALUM 120UF 20% 350V SNAP |
136 | - |
|
Техническая |
Bulk | LGN | Active | 120 µF | ±20% | 350 V | - | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 750 mA @ 120 Hz | 1.0725 A @ 50 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
UKW1V472MHDCAP ALUM 4700UF 20% 35V RADIAL |
712 | - |
|
Техническая |
Bulk | UKW | Not For New Designs | 4700 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 2.49 A @ 120 Hz | 2.8635 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.398 (35.50mm) | - | Through Hole |
|
LAR2W820MELZ25CAP ALUM 82UF 20% 450V SNAP |
190 | - |
|
Техническая |
Bulk | LAR | Active | 82 µF | ±20% | 450 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 340 mA @ 120 Hz | - | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 0.984 (25.00mm) | - | Through Hole |
