+86 15815556552Алюминиево - полимерный конденсатор
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Type | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Ratings | Applications | Features | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
870025575009CAP ALUM POLY 330UF 20% 25V T/H |
1,059 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | WCAP-PTG5 | Active | Polymer | 330 µF | ±20% | 25 V | 20mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 245 mA @ 120 Hz | 4.9 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.551 (14.00mm) | - | Through Hole |
|
EEF-CS1C220RCAP ALUM POLY 22UF 20% 16V SMD |
3,065 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap CS | Not For New Designs | Polymer | 22 µF | ±20% | 16 V | 40mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 3.2 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.047 (1.20mm) | - | Surface Mount |
|
APXE4R0ARA391MF80GCAP ALUM POLY 390UF 20% 4V SMD |
1,763 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | NPCAP™-PXE | Active | Polymer | 390 µF | ±20% | 4 V | 14mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 3.47 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.303 (7.70mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
6SVQP220MCAP ALUM POLY 220UF 20% 6.3V SMD |
1,660 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | OS-CON™, SVQP | Active | Polymer | 220 µF | ±20% | 6.3 V | 35mOhm | 1000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 40.5 mA @ 120 Hz | 810 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.276 (7.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEF-LX0E331R4CAP ALUM POLY 330UF 20% 2.5V SMD |
2,743 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap LX | Active | Polymer | 330 µF | ±20% | 2.5 V | 4.5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 8.5 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.079 (2.00mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
PLE0E821MDO1TDCAP ALUM POLY 820UF 20% 2.5V T/H |
1,870 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | PLE | Not For New Designs | Polymer | 820 µF | ±20% | 2.5 V | 5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 6.6 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
2R5SVPC390MCAP ALUM POLY 390UF 20% 2.5V SMD |
1,945 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | OS-CON™, SVPC | Active | Polymer | 390 µF | ±20% | 2.5 V | 25mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 120.5 mA @ 120 Hz | 2.41 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
4SVPC150MYCAP ALUM POLY 150UF 20% 4V SMD |
1,441 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | OS-CON™, SVPC | Active | Polymer | 150 µF | ±20% | 4 V | 23mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 112 mA @ 120 Hz | 2.24 A @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.236 (6.00mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
EEF-SX0D391XECAP ALUM POLY 390UF 20% 2V SMD |
1,450 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap SX | Active | Polymer | 390 µF | ±20% | 2 V | 6mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 7.5 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.079 (2.00mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
875015119006CAP ALUM POLY 220UF 20% 6.3V SMD |
3,206 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | WCAP-PHGP | Active | Polymer | 220 µF | ±20% | 6.3 V | 15mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 5.1 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.079 (2.00mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
ECASD60D337M007K00CAP ALUM POLY 330UF 20% 2V SMD |
2,500 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | ECAS | Not For New Designs | Polymer | 330 µF | ±20% | 2 V | 7mOhm | 1000 Hrs @ 105°C | -40°C ~ 105°C | - | General Purpose | - | - | 3.5 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.110 (2.80mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
EEF-LR0E181RCAP ALUM POLY 180UF 20% 2.5V SMD |
1,841 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap, LR | Active | Polymer | 180 µF | ±20% | 2.5 V | 4.5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 7.5 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.039 (1.00mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
PLG1A561MCO1TDCAP ALUM POLY 560UF 20% 10V T/H |
1,648 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | PLG | Active | Polymer | 560 µF | ±20% | 10 V | 11mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 5.1 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.354 (9.00mm) | - | Through Hole |
|
|
EEF-LR0D221RCAP ALUM POLY 220UF 20% 2V SMD |
1,323 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap, LR | Active | Polymer | 220 µF | ±20% | 2 V | 4.5mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 7.5 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.039 (1.00mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
16SVPG270MCAP ALUM POLY 270UF 20% 16V SMD |
1,322 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | OS-CON™, SVPG | Active | Polymer | 270 µF | ±20% | 16 V | 8mOhm | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 290 mA @ 120 Hz | 5.8 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.394 (10.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
ECASD31E106M040KA0CAP ALUM POLY 10UF 20% 25V SMD |
2,923 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | ECAS | Last Time Buy | Polymer | 10 µF | ±20% | 25 V | 40mOhm | 2000 Hrs @ 105°C | -40°C ~ 105°C | - | General Purpose | - | - | 1.6 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.059 (1.50mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
|
EEF-SX0E391ERCAP ALUM POLY 390UF 20% 2.5V SMD |
2,038 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap SX | Active | Polymer | 390 µF | ±20% | 2.5 V | 9mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 6.3 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.079 (2.00mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
|
EEF-SX0E331XRCAP ALUM POLY 330UF 20% 2.5V SMD |
1,553 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap SX | Not For New Designs | Polymer | 330 µF | ±20% | 2.5 V | 6mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | - | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.079 (2.00mm) | - | Surface Mount |
|
A700W227M2R5ATE009CAP ALUM POLY 220UF 20% 2.5V SMD |
2,964 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | AO-Cap A700 | Active | Polymer | 220 µF | ±20% | 2.5 V | 9mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | - | 5.7 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.059 (1.50mm) | - | Surface Mount |
|
|
EEF-SX0G151ERCAP ALUM POLY 150UF 20% 4V SMD |
2,523 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | SP-Cap SX | Active | Polymer | 150 µF | ±20% | 4 V | 9mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 6.3 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.079 (2.00mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
