+86 15815556552Алюминиево - полимерный конденсатор
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Type | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Ratings | Applications | Features | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
A768EB127M1DLAS034CAP ALUM POLY 120UF 20% 20V SMD |
5,733 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | A768 | Active | Polymer | 120 µF | ±20% | 20 V | 34mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 65 mA @ 120 Hz | 1.3 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
A768KE107M1VLAE036CAP ALUM POLY 100UF 20% 35V SMD |
2,126 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | A768 | Active | Polymer | 100 µF | ±20% | 35 V | 36mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 70 mA @ 120 Hz | 1.4 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.236 (6.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
APXG200ARA470ME61GCAP ALUM POLY 47UF 20% 20V SMD |
12,260 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | NPCAP™-PXG | Active | Polymer | 47 µF | ±20% | 20 V | 30mOhm | 15000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.8 A @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.240 (6.10mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
|
APXG200ARA121MF61GCAP ALUM POLY 120UF 20% 20V SMD |
14,898 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | NPCAP™-PXG | Active | Polymer | 120 µF | ±20% | 20 V | 25mOhm | 15000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 3.2 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.240 (6.10mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
APXG250ARA470MF61GCAP ALUM POLY 47UF 20% 25V SMD |
254 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | NPCAP™-PXG | Active | Polymer | 47 µF | ±20% | 25 V | 30mOhm | 15000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.8 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.240 (6.10mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
A765EB157M1ALAE022CAP ALUM POLY 150UF 20% 10V SMD |
7,829 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | A765 | Active | Polymer | 150 µF | ±20% | 10 V | 22mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 116 mA @ 120 Hz | 2.32 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
A765BG227M0JLAE020CAP ALUM POLY 220UF 20% 6.3V SMD |
2,263 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | A765 | Active | Polymer | 220 µF | ±20% | 6.3 V | 20mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 135 mA @ 120 Hz | 2.7 A @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.287 (7.30mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
HHXC250ARA470MF61GCAP ALUM POLY 47UF 20% 25V SMD |
4,776 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HXC | Active | Hybrid | 47 µF | ±20% | 25 V | 50mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | - | 900 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.240 (6.10mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
ECASD40J106M055K00CAP ALUM POLY 10UF 20% 6.3V SMD |
12,800 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | ECAS | Not For New Designs | Polymer | 10 µF | ±20% | 6.3 V | 55mOhm | 1000 Hrs @ 105°C | -40°C ~ 105°C | - | General Purpose | - | - | 1 A @ 100 kHz | - | - | 0.287 L x 0.169 W (7.30mm x 4.30mm) | 0.075 (1.90mm) | 0.287 L x 0.169 W (7.30mm x 4.30mm) | Surface Mount |
|
|
A768KE107M1VLAS036CAP ALUM POLY 100UF 20% 35V SMD |
8,000 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | A768 | Active | Polymer | 100 µF | ±20% | 35 V | 36mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 70 mA @ 120 Hz | 1.4 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.236 (6.00mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
6SVPC120MVCAP ALUM POLY 120UF 20% 6.3V SMD |
1,988 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | OS-CON™, SVPC | Active | Polymer | 120 µF | ±20% | 6.3 V | 21mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 98.5 mA @ 120 Hz | 1.97 A @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.236 (6.00mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
A767EB226M1VLAE050CAP ALUM POLY 22UF 20% 35V SMD |
5,128 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | A767 | Active | Polymer | 22 µF | ±20% | 35 V | 50mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 65 mA @ 120 Hz | 1.3 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
A768KS157M1GLAS025CAP ALUM POLY 150UF 20% 40V SMD |
4,927 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | A768 | Active | Polymer | 150 µF | ±20% | 40 V | 25mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 97.5 mA @ 120 Hz | 1.95 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.492 (12.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
RL81C331MDN1KXCAP ALUM POLY 330UF 20% 16V T/H |
6,016 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FPCAP, RL8 | Active | Polymer | 330 µF | ±20% | 16 V | 12mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 500 mA @ 120 Hz | 5 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.354 (9.00mm) | - | Through Hole |
|
875105240001CAP ALUM POLY 10UF 20% 10V SMD |
15,367 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | WCAP-PSLP | Active | Polymer | 10 µF | ±20% | 10 V | 45mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 60 mA @ 120 Hz | 1.2 A @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.217 (5.50mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
875105142001CAP ALUM POLY 47UF 20% 6.3V SMD |
7,624 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | WCAP-PSLP | Active | Polymer | 47 µF | ±20% | 6.3 V | 30mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 98.5 mA @ 120 Hz | 1.97 A @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.217 (5.50mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
RNE1C101MDS1PXCAP ALUM POLY 100UF 20% 16V T/H |
13,058 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FPCAP, RNE | Active | Polymer | 100 µF | ±20% | 16 V | 35mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 230 mA @ 120 Hz | 2.3 A @ 100 kHz | - | 0.197 (5.00mm) | 0.197 Dia (5.00mm) | 0.433 (11.00mm) | - | Through Hole |
|
PCF0J121MCL1GSCAP ALUM POLY 120UF 20% 6.3V SMD |
4,990 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | PCF | Active | Polymer | 120 µF | ±20% | 6.3 V | 23mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 3 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
RS61E330MCN1JTCAP ALUM POLY 33UF 20% 25V T/H |
8,992 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FPCAP, RS6 | Active | Polymer | 33 µF | ±20% | 25 V | 60mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 170 mA @ 120 Hz | 1.7 A @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.236 (6.00mm) | - | Through Hole |
|
APXC100ARA560ME60GCAP ALUM POLY 56UF 20% 10V SMD |
1,838 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | NPCAP™-PXC | Active | Polymer | 56 µF | ±20% | 10 V | 40mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.66 A @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.224 (5.70mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
