| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BD860S_L2_00001SURFACE MOUNT SCHOTTKY BARRIER R |
2,100 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 50 µA @ 60 V | 60 V | 8A | -65°C ~ 175°C | 750 mV @ 8 A | ||
|
|
UF2GF_R1_00001SURFACE MOUNT ULTRA FAST RECTIFI |
2,835 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 27pF @ 4V, 1MHz | 50 ns | 1 µA @ 400 V | 400 V | 2A | -55°C ~ 150°C | 1.4 V @ 2 A | ||
|
|
SB1020_T0_00001SCHOTTKY BARRIER RECTIFIERS |
2,970 | - |
|
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 200 µA @ 20 V | 20 V | 10A | -55°C ~ 125°C | 550 mV @ 10 A | ||
|
|
BD8200S_L2_00001SURFACE MOUNT SCHOTTKY BARRIER R |
2,367 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 50 µA @ 200 V | 200 V | 8A | -65°C ~ 175°C | 900 mV @ 8 A | ||
|
|
UF2DF_R1_00001SURFACE MOUNT ULTRA FAST RECTIFI |
2,796 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 37pF @ 4V, 1MHz | 50 ns | 1 µA @ 200 V | 200 V | 2A | -55°C ~ 150°C | 1 V @ 2 A | ||
|
|
SB1030_T0_00001SCHOTTKY BARRIER RECTIFIERS |
2,823 | - |
|
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 200 µA @ 30 V | 30 V | 10A | -55°C ~ 125°C | 550 mV @ 10 A | ||
|
|
SVM1550UA_R2_00001LOW VF SCHOTTKY RECTIFIER |
3,786 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 320 µA @ 50 V | 50 V | 15A | -55°C ~ 150°C | 490 mV @ 15 A | ||
|
|
UF1JF_R1_00001SURFACE MOUNT ULTRA FAST RECTIFI |
2,463 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 8pF @ 4V, 1MHz | 100 ns | 1 µA @ 600 V | 600 V | 1A | -55°C ~ 150°C | 1.7 V @ 1 A | ||
|
|
SB1045_T0_00001SCHOTTKY BARRIER RECTIFIER |
3,390 | - |
|
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 200 µA @ 45 V | 45 V | 10A | -55°C ~ 150°C | 550 mV @ 10 A | ||
|
SVM1060X_R1_00001TO-277, SKY |
2,519 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 850pF @ 4V, 1MHz | - | 360 µA @ 60 V | 60 V | 10A | -55°C ~ 150°C | 490 mV @ 10 A | |
|
|
SVT15100U_R1_00001EXTREME LOW VF SCHOTTKY BARRIER |
3,329 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 80 µA @ 100 V | 100 V | 15A | -55°C ~ 150°C | 660 mV @ 15 A | ||
|
|
QRT1506D_R2_00001PLANAR STRUCTURED SUPERFAST RECO |
3,620 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 40 ns | 3 µA @ 600 V | 600 V | 15A | -55°C ~ 175°C | 2.35 V @ 15 A | ||
|
|
SVT1560V_R1_00001ULTRA LOW VF SCHOTTKY RECTIFIER |
3,316 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 250 µA @ 60 V | 60 V | 15A | -55°C ~ 150°C | 510 mV @ 15 A | ||
|
|
ER2C_R1_00001SURFACE MOUNT RECTIFIER |
2,657 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 25pF @ 4V, 1MHz | 35 ns | 1 µA @ 150 V | 150 V | 2A | -55°C ~ 150°C | 950 mV @ 2 A | ||
|
|
SB1545S_AY_00001SCHOTTKY RECTIFIERS |
2,120 | - |
|
Cut Tape (CT),Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 200 µA @ 45 V | 45 V | 15A | -55°C ~ 150°C | 500 mV @ 15 A | ||
|
|
SVM1560V_R1_00001ULTRA LOW VF SCHOTTKY RECTIFIER |
2,631 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 60 V | 60 V | 15A | -55°C ~ 150°C | 590 mV @ 15 A | ||
|
|
FR3B_R1_00001FAST SWITCHING SURFACE MOUNT REC |
3,986 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 60pF @ 4V, 1MHz | 150 ns | 1 µA @ 100 V | 100 V | 3A | -50°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
SVT15120U_R1_00001EXTREME LOW VF SCHOTTKY BARRIER |
3,824 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 35 µA @ 120 V | 120 V | 15A | -55°C ~ 150°C | 790 mV @ 15 A | ||
|
|
ER2A_R1_00001SURFACE MOUNT RECTIFIER |
2,288 | - |
|
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 25pF @ 4V, 1MHz | 35 ns | 1 µA @ 50 V | 50 V | 2A | -55°C ~ 150°C | 950 mV @ 2 A | ||
|
PSDP15120S1_T0_00001TO-220AC, FAST |
3,342 | - |
|
Техническая |
Tube | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 105 ns | 100 µA @ 1200 V | 1200 V | 15A | -55°C ~ 150°C | 3.5 V @ 15 A |
