Производитель Часть #	Доступность	Цена	Количество	Техническая	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B66417U0160K187 FERRITE CORE EFD N87 1PC EPCOS - TDK Electronics	2,421	-	запрос цен	Техническая	Box	EFD20/10/7	Active	EFD	EFD 20 x 10 x 7	N87	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.394 (10.00mm)
B66417U0250K187 FERRITE CORE EPCOS - TDK Electronics	3,812	-	запрос цен	Техническая	Box	EFD20/10/7	Active	EFD	EFD 20 x 10 x 7	N87	-	-	±10%	Gapped	300	2200	1.52	47	31	31	1460	Uncoated	0.394 (10.00mm)
B66307G0240X187 FERRITE CORE EPCOS - TDK Electronics	3,799	-	запрос цен	Техническая	Box	E16/8/5	Active	E	E 16 x 8 x 5	N87	-	-	-	Gapped	-	2200	1.87	37.6	20.1	19.4	756	Uncoated	0.323 (8.20mm)
B66317G0000X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	3,559	-	запрос цен	Техническая	Box	E25/13/7	Active	E	E 25 x 13 x 7	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.504 (12.80mm)
B66307G0100X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	2,396	-	запрос цен	Техническая	Box	E16/8/5	Active	E	E 16 x 8 x 5	N87	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.323 (8.20mm)
B66307G0500X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	3,304	-	запрос цен	Техническая	Box	E16/8/5	Active	E	E 16 x 8 x 5	N87	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.323 (8.20mm)
B64290L0062X046 FERRITE CORE TOROID 6.4UH T46 EPCOS - TDK Electronics	3,331	-	запрос цен	Техническая	Box	TX9.5/4.8/3.2	Active	Toroid	-	T46	0.413 (10.50mm)	6.4 µH	±30%	Ungapped	-	15000	2.85	20.72	7.28	-	151	Epoxy	0.161 (4.10mm)
B66317G0160X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	2,744	-	запрос цен	Техническая	Box	E25/13/7	Active	E	E 25 x 13 x 7	N87	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.504 (12.80mm)
B66417G0000X187 FERRITE CORE EFD N87 1PC EPCOS - TDK Electronics	3,729	-	запрос цен	Техническая	Box	EFD20/10/7	Active	EFD	EFD 20 x 10 x 7	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.394 (10.00mm)
B66302G0000X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	2,411	-	запрос цен	Техническая	Box	E8.8/4/2	Active	E	E 8 x 8	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.161 (4.10mm)
B64290P0751X038 FERRITE CORE TOROID 5.5UH T38 EPCOS - TDK Electronics	2,932	-	запрос цен	Техническая	Box	TC8/4/4	Active	Toroid	-	T38	0.316 (8.02mm)	5.5 µH	±30%	Ungapped	-	10000	2.26	17.42	7.7	-	134	Parylene	0.158 (4.02mm)
B66417G0000X197 FERRITE CORE EFD N97 1PC EPCOS - TDK Electronics	3,633	-	запрос цен	Техническая	Box	EFD20/10/7	Active	EFD	EFD 20 x 10 x 7	N97	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.394 (10.00mm)
B65523J0000R087 FERRITE CORE ER 800NH N87 2PCS EPCOS - TDK Electronics	2,694	-	запрос цен	Техническая	Box	ER9.5	Active	ER	ER 9.5 x 5	N87	-	800 nH	-20%, +30%	Ungapped	1000	2200	1.54	13.6	8.81	-	120	Uncoated	0.098 (2.50mm)
B64290A0045X035 FERRITE CORE TOROID 3.87UH T35 EPCOS - TDK Electronics	2,573	-	запрос цен	Техническая	Box	T16/9.6/6.3	Active	Toroid	R 16 x 9.6 x 6.3	T35	0.630 (16.00mm)	3.87 µH	±25%	Ungapped	-	6000	1.95	38.52	19.73	-	760	Uncoated	0.248 (6.30mm)
B66417G0000X149 FERRITE CORE EFD N49 1PC EPCOS - TDK Electronics	2,185	-	запрос цен	Техническая	Box	EFD20/10/7	Active	EFD	EFD 20 x 10 x 7	N49	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.394 (10.00mm)
B64290L0045X038 FERRITE CORE TOROID 6.44UH T38 EPCOS - TDK Electronics	3,238	-	запрос цен	Техническая	Bulk	TX16/9.6/6.3	Active	Toroid	-	T38	0.677 (17.20mm)	6.44 µH	±30%	Ungapped	-	10000	1.95	38.52	19.73	-	760	Epoxy	0.287 (7.30mm)
B64290L0638X830 FERRITE CORE TOROID 2.61UH N30 EPCOS - TDK Electronics	3,897	-	запрос цен	Техническая	Box	TX22/14/6.4	Active	Toroid	-	N30	0.917 (23.30mm)	2.61 µH	±25%	Ungapped	-	4300	2.07	54.15	26.17	-	1417	Epoxy	0.291 (7.40mm)
B66421G0000X197 FERRITE CORE EFD N97 1PC EPCOS - TDK Electronics	2,302	-	запрос цен	Техническая	Box	EFD25/13/9	Active	EFD	EFD 25 x 13 x 9	N97	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.492 (12.50mm)
B64290L0632X830 FERRITE CORE TOROID 4.16UH N30 EPCOS - TDK Electronics	3,469	-	запрос цен	Техническая	Bulk	TX20/10/7	Active	Toroid	-	N30	0.835 (21.20mm)	4.16 µH	±25%	Ungapped	-	4300	1.3	43.55	33.63	-	1465	Epoxy	0.319 (8.10mm)
B62152A0004X030 FERRITE CORE 2 HOLE 10UH N30 EPCOS - TDK Electronics	2,792	-	запрос цен	Техническая	Box	MHB2-14.5/8.5/8.3	Active	Multi-Hole (2)	-	N30	-	10 µH	±30%	Ungapped	-	4300	0.54	15.3	28.4	-	435	Uncoated	0.327 (8.30mm)
