| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0805LS-153XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
2,547 | - |
|
Техническая |
0805 (2012 Metric) | Strip | 0805LS | Active | - | Ceramic, Ferrite | 15 µH | - | 180 mA | - | Unshielded | 5.03Ohm Max | - | 17MHz | AEC-Q200 | -40°C ~ 100°C | 2.5 MHz | - | Surface Mount | - |
|
|
0805LS-681XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
2,539 | - |
|
Техническая |
0805 (2012 Metric) | Strip | 0805LS | Active | - | Ceramic, Ferrite | 680 nH | - | 590 mA | - | Unshielded | 460mOhm Max | - | 400MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
0603LS-181XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
1,578 | - |
|
Техническая |
0603 (1608 Metric) | Strip | 0603LS | Active | - | Ceramic, Ferrite | 180 nH | - | 1.3 A | - | Unshielded | 150mOhm Max | - | 950MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
|
0603LS-101XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
1,481 | - |
|
Техническая |
0603 (1608 Metric) | Strip | 0603LS | Active | - | Ceramic, Ferrite | 100 nH | - | 1.4 A | - | Unshielded | 130mOhm Max | - | 1.15GHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
|
0603LS-561XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
1,431 | - |
|
Техническая |
0603 (1608 Metric) | Strip | 0603LS | Active | - | Ceramic, Ferrite | 560 nH | - | 550 mA | - | Unshielded | 440mOhm Max | - | 525MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
|
0805LS-682XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
2,560 | - |
|
Техническая |
0805 (2012 Metric) | Strip | 0805LS | Active | - | Ceramic, Ferrite | 6.8 µH | - | 260 mA | - | Unshielded | 2.25Ohm Max | - | 35MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
|
0805LS-103XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
1,273 | - |
|
Техническая |
0805 (2012 Metric) | Strip | 0805LS | Active | - | Ceramic, Ferrite | 10 µH | - | 200 mA | - | Unshielded | 3.45Ohm Max | - | 21MHz | AEC-Q200 | -40°C ~ 100°C | 2.5 MHz | - | Surface Mount | - |
|
|
0603LS-822XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
1,058 | - |
|
Техническая |
0603 (1608 Metric) | Strip | 0603LS | Active | - | Ceramic, Ferrite | 8.2 µH | - | 190 mA | - | Unshielded | 3.6Ohm Max | - | 26MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
|
0603LS-121XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
960 | - |
|
Техническая |
0603 (1608 Metric) | Strip | 0603LS | Active | - | Ceramic, Ferrite | 120 nH | - | 1.4 A | - | Unshielded | 150mOhm Max | - | 1.1GHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
|
0603LS-151XGRCRF INDUCTOR, FERRITE CORE, 2% TO |
342 | - |
|
Техническая |
0603 (1608 Metric) | Strip | 0603LS | Active | - | Ceramic, Ferrite | 150 nH | - | 1.3 A | - | Unshielded | 150mOhm Max | - | 106MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | - |
|
MSS6132-472MLCPOWER INDUCTOR, SHIELDED, 20% TO |
110,915 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 4.7 µH | - | 3.1 A | 2.84A | Shielded | 43mOhm Max | - | 65MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-103MLCPOWER INDUCTOR, SHIELDED, 20% TO |
64,023 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 10 µH | - | 2.5 A | 1.84A | Shielded | 70mOhm Max | - | 39MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-473MLCPOWER INDUCTOR, SHIELDED, 20% TO |
24,111 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 47 µH | - | 1.3 A | 930mA | Shielded | 300mOhm Max | - | 16MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-682MLCPOWER INDUCTOR, SHIELDED, 20% TO |
23,052 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 6.8 µH | - | 2.8 A | 2.3A | Shielded | 52mOhm Max | - | 47MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-223MLCPOWER INDUCTOR, SHIELDED, 20% TO |
10,343 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 22 µH | - | 1.9 A | 1.22A | Shielded | 158mOhm Max | - | 21MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-153MLCPOWER INDUCTOR, SHIELDED, 20% TO |
5,322 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 15 µH | - | 2.2 A | 1.56A | Shielded | 106mOhm Max | - | 27MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-273MLCPOWER INDUCTOR, SHIELDED, 20% TO |
3,687 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 27 µH | - | 1.75 A | 1.18A | Shielded | 180mOhm Max | - | 19MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-563MLCPOWER INDUCTOR, SHIELDED, 20% TO |
1,044 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 56 µH | - | 1.15 A | 790mA | Shielded | 380mOhm Max | - | 14MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-333MLCPOWER INDUCTOR, SHIELDED, 20% TO |
2,466 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 33 µH | - | 1.6 A | 1.1A | Shielded | 250mOhm Max | - | 18MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
MSS6132-183MLCPOWER INDUCTOR, SHIELDED, 20% TO |
2,779 | - |
|
Техническая |
Nonstandard | Strip | MSS6132 | Active | - | Ferrite | 18 µH | - | 2.05 A | 1.36A | Shielded | 118mOhm Max | - | 24MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
