+86 15815556552Постоянный индуктор
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRN4018TA-101MFIXED IND 100UH 340MA 1.38OHM SM |
5,002 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN4018TA | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±20% | 340 mA | 420mA | Semi-Shielded | 1.38Ohm | 10 @ 100kHz | 4MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
CC453232-3R3KLFIXED IND 3.3UH 750MA 220MOHM SM |
2,007 | - |
|
Техническая |
1812 (4532 Metric) | Tape & Reel (TR),Cut Tape (CT) | CC453232 | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±10% | 750 mA | - | Unshielded | 220mOhm Max | 10 @ 7.96MHz | 45MHz | - | -40°C ~ 125°C | 7.96 MHz | - | Surface Mount | 1812 |
|
SRN5020-330MFIXED IND 33UH 900MA 516MOHM SMD |
20,145 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN5020 | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±20% | 900 mA | 800mA | Semi-Shielded | 516mOhm Max | 11 @ 2.52MHz | 10MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
SRN5020-1R0YFIXED IND 1UH 3.6A 25 MOHM SMD |
13,852 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN5020 | Active | Drum Core, Wirewound | Ferrite | 1 µH | ±30% | 3.6 A | 4A | Semi-Shielded | 25mOhm Max | 13 @ 7.96MHz | 85MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
SRN6028-330MFIXED IND 33UH 1.1A 264 MOHM SMD |
3,062 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN6028 | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±20% | 1.1 A | 1.1A | Semi-Shielded | 264mOhm Max | 11 @ 2.52MHz | 10MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
SRN5020-5R6MFIXED IND 5.6UH 1.8A 106MOHM SMD |
3,803 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN5020 | Active | Drum Core, Wirewound | Ferrite | 5.6 µH | ±20% | 1.8 A | 1.8A | Semi-Shielded | 106mOhm Max | 11 @ 7.96MHz | 28MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
SRN5040-6R8MFIXED IND 6.8UH 2.3A 59 MOHM SMD |
2,101 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN5040 | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±20% | 2.3 A | 2.6A | Semi-Shielded | 59mOhm Max | 15 @ 7.96MHz | 21MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
CM453232-391JLFIXED IND 390UH 80MA 18 OHM SMD |
360 | - |
|
Техническая |
1812 (4532 Metric) | Tape & Reel (TR),Cut Tape (CT) | CM45 | Active | Drum Core, Wirewound | Ferrite | 390 µH | ±5% | 80 mA | - | Unshielded | 18Ohm Max | 40 @ 796kHz | 3MHz | - | -40°C ~ 125°C | 796 kHz | - | Surface Mount | 1812 |
|
|
CM453232-1R2JLFIXED IND 1.2UH 430MA 550MOHM SM |
1,970 | - |
|
Техническая |
1812 (4532 Metric) | Tape & Reel (TR),Cut Tape (CT) | CM45 | Active | Drum Core, Wirewound | Ferrite | 1.2 µH | ±5% | 430 mA | - | Unshielded | 550mOhm Max | 50 @ 7.96MHz | 80MHz | - | -40°C ~ 125°C | 7.96 MHz | - | Surface Mount | 1812 |
|
SRN3015TA-150MFIXED IND 15UH 700MA 320MOHM SMD |
3,536 | - |
|
Техническая |
1212 (3030 Metric) | Tape & Reel (TR),Cut Tape (CT) | SRN3015TA | Active | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 700 mA | 650mA | Semi-Shielded | 320mOhm | 12 @ 100kHz | 23MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
SRP2510A-R33MFIXED IND 330NH 4.4A 26 MOHM SMD |
3,054 | - |
|
Техническая |
1008 (2520 Metric) | Tape & Reel (TR),Cut Tape (CT) | SRP2510A | Active | Drum Core, Wirewound | Iron Powder | 330 nH | ±20% | 4.4 A | 6.6A | Shielded | 26mOhm Max | 35 @ 1MHz | 170MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 |
|
|
SRP2510A-2R2MFIXED IND 2.2UH 2.3A 119MOHM SMD |
5,000 | - |
|
Техническая |
1008 (2520 Metric) | Tape & Reel (TR),Cut Tape (CT) | SRP2510A | Active | Drum Core, Wirewound | Iron Powder | 2.2 µH | ±20% | 2.3 A | 2.4A | Shielded | 119mOhm Max | 35 @ 1MHz | 57MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 |
|
|
SRP2512A-R68MFIXED IND 680NH 3.7A 35 MOHM SMD |
3,930 | - |
|
Техническая |
1008 (2520 Metric) | Tape & Reel (TR),Cut Tape (CT) | SRP2512A | Active | Drum Core, Wirewound | Iron Powder | 680 nH | ±20% | 3.7 A | 5A | Shielded | 35mOhm Max | 39 @ 1MHz | 104MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1008 |
|
SRN5040TA-680KFIXED IND 68UH 800MA 400MOHM SMD |
3,914 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN5040TA | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±10% | 800 mA | 900mA | Semi-Shielded | 400mOhm | 15 @ 100kHz | 10MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
SRN5040TA-3R3MFIXED IND 3.3UH 3.5A 24 MOHM SMD |
3,000 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN5040TA | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 3.5 A | 4.4A | Semi-Shielded | 24mOhm | 15 @ 100kHz | 48MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
SRN5040TA-150MFIXED IND 15UH 1.8A 80 MOHM SMD |
2,434 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRN5040TA | Active | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 1.8 A | 2A | Semi-Shielded | 80mOhm | 15 @ 100kHz | 22MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
SDR0302-3R9MLFIXED IND 3.9UH 1.3A 120MOHM SMD |
9,972 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SDR0302 | Active | Drum Core, Wirewound | Ferrite | 3.9 µH | ±20% | 1.3 A | 1.5A | Unshielded | 120mOhm Max | 24 @ 7.96MHz | 50MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - |
|
|
SDR0302-3R3MLFIXED IND 3.3UH 1.4A 110MOHM SMD |
4,026 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SDR0302 | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 1.4 A | 1.6A | Unshielded | 110mOhm Max | 23 @ 7.96MHz | 68MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - |
|
|
SDR0302-1R8MLFIXED IND 1.8UH 1.8A 80 MOHM SMD |
4,846 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SDR0302 | Active | Drum Core, Wirewound | Ferrite | 1.8 µH | ±20% | 1.8 A | 2A | Unshielded | 80mOhm Max | 23 @ 7.96MHz | 85MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - |
|
|
SDR0302-331KLFIXED IND 330UH 130MA 10 OHM SMD |
4,144 | - |
|
Техническая |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SDR0302 | Active | Drum Core, Wirewound | Ferrite | 330 µH | ±10% | 130 mA | 150mA | Unshielded | 10Ohm Max | 40 @ 796kHz | 6MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - |
