+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-FN1A151VCAP ALUM 150UF 20% 10V SMD |
144 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 150 µF | ±20% | 10 V | 360mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 156 mA @ 120 Hz | 240 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.252 (6.40mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EEE-TC1C221VCAP ALUM 220UF 20% 16V SMD |
3,029 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | TC, Anti-Vibration | Active | 220 µF | ±20% | 16 V | 200mOhm @ 100kHz | 3000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 266.5 mA @ 120 Hz | 410 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEE-FK1E471AVCAP ALUM 470UF 20% 25V SMD |
1,200 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FK, Anti-Vibration | Active | 470 µF | ±20% | 25 V | 80mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 552.5 mA @ 120 Hz | 850 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEE-TC1A331PCAP ALUM 330UF 20% 10V SMD |
452 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | TC | Active | 330 µF | ±20% | 10 V | 150mOhm @ 100kHz | 3000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 487.5 mA @ 120 Hz | 750 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEE-HB1C331APCAP ALUM 330UF 20% 16V SMD |
473 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HB | Active | 330 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 230 mA @ 120 Hz | 391 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.402 (10.20mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEE-FNE151XUVCAP ALUM 150UF 20% 25V SMD |
556 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 150 µF | ±20% | 25 V | 340mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 182 mA @ 120 Hz | 280 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.327 (8.30mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EEE-FN1E101UVCAP ALUM 100UF 20% 25V SMD |
960 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 100 µF | ±20% | 25 V | 360mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 156 mA @ 120 Hz | 240 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.252 (6.40mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EEU-FS0J562BCAP ALUM 5600UF 20% 6.3V RADIAL |
216 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 5600 µF | ±20% | 6.3 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.552 A @ 120 Hz | 3.19 A @ 100 kHz | 15 mOhms | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
EEE-FNV121XUVCAP ALUM 120UF 20% 35V SMD |
239 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 120 µF | ±20% | 35 V | 340mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 182 mA @ 120 Hz | 280 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.327 (8.30mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EEE-FNJ471XUVCAP ALUM 470UF 20% 6.3V SMD |
163 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 470 µF | ±20% | 6.3 V | 340mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 182 mA @ 120 Hz | 280 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.327 (8.30mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EEE-TC1A331UVCAP ALUM 330UF 20% 10V SMD |
3,670 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | TCU, Anti-Vibration | Active | 330 µF | ±20% | 10 V | 200mOhm @ 100kHz | 3000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 266.5 mA @ 120 Hz | 410 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FK1E681SVCAP ALUM 680UF 20% 25V SMD |
2,150 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FKS, Anti-Vibration | Active | 680 µF | ±20% | 25 V | 80mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 552.5 mA @ 120 Hz | 850 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEU-EB1J471BCAP ALUM 470UF 20% 63V RADIAL |
455 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | EB-A | Active | 470 µF | ±20% | 63 V | - | 10000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 454 mA @ 120 Hz | 590.2 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
EEE-TP1A221AVCAP ALUM 220UF 20% 10V SMD |
178 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | TP, Anti-Vibration | Active | 220 µF | ±20% | 10 V | 200mOhm @ 100kHz | 3000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 175.5 mA @ 120 Hz | 270 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
ECE-A1EN471UBCAP ALUM 470UF 20% 25V RADIAL |
289 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | SU | Active | 470 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | 430 mA @ 120 Hz | 731 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.492 Dia (12.50mm) | 0.866 (22.00mm) | - | Through Hole |
|
|
EEE-TC1A331VCAP ALUM 330UF 20% 10V SMD |
493 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | TC, Anti-Vibration | Active | 330 µF | ±20% | 10 V | 150mOhm @ 100kHz | 3000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 487.5 mA @ 120 Hz | 750 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEE-FN1J470VCAP ALUM 47UF 20% 63V SMD |
464 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 47 µF | ±20% | 63 V | 650mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 162.5 mA @ 120 Hz | 250 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FN1V221VCAP ALUM 220UF 20% 35V SMD |
430 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN, Anti-Vibration | Active | 220 µF | ±20% | 35 V | 160mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 390 mA @ 120 Hz | 600 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-FPV391UAVCAP ALUM 390UF 20% 35V SMD |
2,612 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FP, Anti-Vibration | Active | 390 µF | ±20% | 35 V | 80mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, High Temperature Reflow | 552.5 mA @ 120 Hz | 850 mA @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEE-FP1A221AVCAP ALUM 220UF 20% 10V SMD |
749 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FP, Anti-Vibration | Active | 220 µF | ±20% | 10 V | 180mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 325 mA @ 120 Hz | 500 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.256 (6.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
