+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B41570A7688Q000CAP ALUM 6800UF 40V SCREW |
2,418 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 6800 µF | -10%, +30% | 40 V | 28mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 8.4 A @ 100 Hz | - | 17 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
B41570A9158Q000CAP ALUM 1500UF 100V SCREW |
3,267 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 1500 µF | -10%, +30% | 100 V | 83mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 4.2 A @ 100 Hz | - | 34 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 2.232 (56.70mm) | - | Chassis Mount |
|
|
B41570E4109Q000CAP ALUM 10000UF 16V SCREW |
3,080 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 10000 µF | -10%, +30% | 16 V | 38mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 6.2 A @ 100 Hz | - | 26 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 2.232 (56.70mm) | - | Chassis Mount |
|
|
B41570E4159Q000CAP ALUM 15000UF 16V SCREW |
3,598 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 15000 µF | -10%, +30% | 16 V | 26mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 8.1 A @ 100 Hz | - | 21 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E4229Q000CAP ALUM 22000UF 16V SCREW |
2,751 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 22000 µF | -10%, +30% | 16 V | 21mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 10 A @ 100 Hz | - | 18 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E4339Q000CAP ALUM 33000UF 16V SCREW |
2,963 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 33000 µF | -10%, +30% | 16 V | 17mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 12 A @ 100 Hz | - | 13 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 4.201 (106.70mm) | - | Chassis Mount |
|
|
B41570E5109Q000CAP ALUM 10000UF 25V SCREW |
2,559 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 10000 µF | -10%, +30% | 25 V | 28mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 7.5 A @ 100 Hz | - | 21 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E5159Q000CAP ALUM 15000UF 25V SCREW |
3,908 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 15000 µF | -10%, +30% | 25 V | 24mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 9.4 A @ 100 Hz | - | 17 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E5229Q000CAP ALUM 22000UF 25V SCREW |
3,864 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 22000 µF | -10%, +30% | 25 V | 20mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 11 A @ 100 Hz | - | 15 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 4.201 (106.70mm) | - | Chassis Mount |
|
|
B41570E5339Q000CAP ALUM 33000UF 25V SCREW |
3,594 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 33000 µF | -10%, +30% | 25 V | 13mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 15 A @ 100 Hz | - | 12 mOhms | 0.874 (22.20mm) | 2.032 Dia (51.60mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E7109Q000CAP ALUM 10000UF 40V SCREW |
2,378 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 10000 µF | -10%, +30% | 40 V | 27mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 9.4 A @ 100 Hz | - | 14 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E7159Q000CAP ALUM 15000UF 40V SCREW |
3,110 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 15000 µF | -10%, +30% | 40 V | 15mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 11 A @ 100 Hz | - | 15 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 4.201 (106.70mm) | - | Chassis Mount |
|
|
B41570E7229Q000CAP ALUM 22000UF 40V SCREW |
2,416 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 22000 µF | -10%, +30% | 40 V | 13mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 15 A @ 100 Hz | - | 13 mOhms | 0.874 (22.20mm) | 2.032 Dia (51.60mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
B41570E7478Q000CAP ALUM 4700UF 40V SCREW |
2,749 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 4700 µF | -10%, +30% | 40 V | 33mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 7.2 A @ 100 Hz | - | 24 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 2.232 (56.70mm) | - | Chassis Mount |
|
B41570E8109Q000CAP ALUM 10000UF 63V SCREW |
2,499 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 10000 µF | -10%, +30% | 63 V | 18mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 13 A @ 100 Hz | - | 14 mOhms | 0.874 (22.20mm) | 2.032 Dia (51.60mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E8228Q000CAP ALUM 2200UF 63V SCREW |
2,245 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 2200 µF | -10%, +30% | 63 V | 60mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 4.7 A @ 100 Hz | - | 30 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 2.232 (56.70mm) | - | Chassis Mount |
|
|
B41570E8338Q000CAP ALUM 3300UF 63V SCREW |
3,731 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 3300 µF | -10%, +30% | 63 V | 39mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 6.8 A @ 100 Hz | - | 24 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
B41570E8478Q000CAP ALUM 4700UF 63V SCREW |
3,919 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 4700 µF | -10%, +30% | 63 V | 31mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 8.7 A @ 100 Hz | - | 20 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
|
|
B41570E8688Q000CAP ALUM 6800UF 63V SCREW |
2,401 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 6800 µF | -10%, +30% | 63 V | 23mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 10 A @ 100 Hz | - | 17 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 4.201 (106.70mm) | - | Chassis Mount |
|
|
B41570E9228Q000CAP ALUM 2200UF 100V SCREW |
2,250 | - |
|
Техническая |
Bulk | B41570 | Obsolete | 2200 µF | -10%, +30% | 100 V | 57mOhm @ 100Hz | 10000 Hrs @ 105°C | - | Polar | - | General Purpose | 5.9 A @ 100 Hz | - | 30 mOhms | 0.500 (12.70mm) | 1.406 Dia (35.70mm) | 3.217 (81.70mm) | - | Chassis Mount |
