Производитель Часть #	Доступность	Цена	Количество	Техническая	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
5977000621 77 TOROID PLASTIC COATED Fair-Rite Products Corp.	3,565	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	77	0.860 (21.84mm)	1.27 µH	-30%, +25%	Ungapped	-	2000	2.131	51.8	24.3	-	1261	Plastic	0.280 (7.11mm)
6698323121 98 PQ CORE SET Fair-Rite Products Corp.	210	-	запрос цен	Техническая	Bulk	-	Active	PQ	-	-	-	-	±25%	Ungapped	-	2400	45.9	75.3	164.2	140.1	12370	Uncoated	-
5977001621 77 TOROID PLASTIC COATED Fair-Rite Products Corp.	422	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	77	1.274 (32.35mm)	1.665 µH	-30%, +25%	Ungapped	-	2000	1.6226	75.7	46.6	-	3532	Plastic	0.343 (8.70mm)
5977001721 77 TOROID PLASTIC COATED Fair-Rite Products Corp.	154	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	77	1.299 (33.00mm)	2.09 µH	-30%, +25%	Ungapped	-	2000	1.2947	76.4	59	-	4510	Plastic	0.406 (10.30mm)
4278453509 78 SLEEVE Fair-Rite Products Corp.	632	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	78	-	-	-	Ungapped	-	2300	-	-	-	-	-	Uncoated	-
5698302021 98 POT CORE SET Fair-Rite Products Corp.	212	-	запрос цен	Техническая	Bulk	-	Active	PS	-	-	1.181 (30.00mm)	-	±25%	Ungapped	-	2400	35.6	45.3	127	-	5750	Uncoated	-
5967001201 67 TOROID Fair-Rite Products Corp.	341	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	67	1.142 (29.00mm)	-	-	Ungapped	-	40	-	73	68	-	5000	Uncoated	0.545 (13.84mm)
5977002721 77 TOROID PLASTIC COATED Fair-Rite Products Corp.	229	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	77	1.449 (36.80mm)	2.25 µH	-30%, +25%	Ungapped	-	2000	1.1361	89.1	78.4	-	6991	Plastic	0.539 (13.70mm)
9595494902 95 ETD CORE SET Fair-Rite Products Corp.	108	-	запрос цен	Техническая	Bulk	-	Active	ETD	-	95	-	-	±25%	Ungapped	-	3000	53	114.4	213.5	209	24420	Uncoated	-
5975011101 75 TOROID Fair-Rite Products Corp.	140	-	запрос цен	Техническая	Box	-	Active	Toroid	-	75	2.900 (73.66mm)	-	±25%	Ungapped	-	5000	-	167	215	-	35900	Uncoated	0.500 (12.70mm)
4078377511 78 ROD Fair-Rite Products Corp.	2,269	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	78	0.374 (9.50mm)	-	-	Ungapped	29	2300	-	25	7.07	-	-	Uncoated	-
5943000221 43 TOROID PLASTIC COATED Fair-Rite Products Corp.	459	-	запрос цен	Техническая	Box	-	Active	Toroid	-	43	0.402 (10.20mm)	350 nH	-25%, +20%	Ungapped	-	800	2.8549	20.7	7.25	-	150	Plastic	0.150 (3.81mm)
4052235211 52 ROD Fair-Rite Products Corp.	306	-	запрос цен	Техническая	Box	-	Active	ROD	-	52	0.236 (6.00mm)	-	-	Ungapped	29	250	-	25	7.07	-	-	Uncoated	-
5943001301 43 TOROID Fair-Rite Products Corp.	465	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	43	1.000 (25.40mm)	-	±20%	Ungapped	-	800	-	62	30.8	-	1900	Uncoated	0.250 (6.35mm)
5961004921 61 TOROID PLASTIC COATED Fair-Rite Products Corp.	2,179	-	запрос цен	Техническая	Tape & Reel (TR)	-	Active	Toroid	-	61	0.665 (16.90mm)	80 nH	±25%	Ungapped	-	125	1.937	38.5	19.9	-	766	Plastic	0.280 (7.11mm)
4061266011 61 SOLID ROD Fair-Rite Products Corp.	759	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	61	0.250 (6.35mm)	-	-	Ungapped	-	125	-	-	-	-	-	Uncoated	-
5961001821 61 TOROID PLASTIC COATED Fair-Rite Products Corp.	316	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	61	0.906 (23.00mm)	75 nH	±25%	Ungapped	-	125	2.0692	54.2	26.2	-	1416	Plastic	0.280 (7.11mm)
5977001401 77 TOROID Fair-Rite Products Corp.	557	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	77	1.000 (25.40mm)	-	±25%	Ungapped	-	2000	-	62	41	-	2520	Uncoated	0.320 (8.13mm)
4077375411 77 SOLID ROD Fair-Rite Products Corp.	255	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	77	0.374 (9.50mm)	-	-	Ungapped	29	2000	-	25	7.07	-	-	Uncoated	-
3061990901 61 ROD Fair-Rite Products Corp.	791	-	запрос цен	Техническая	Tray	-	Active	ROD	-	61	0.236 (6.00mm)	-	-	Ungapped	22	125	-	-	28.3	-	-	Uncoated	-
