Производитель Часть #	Доступность	Цена	Количество	Техническая	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B65525J0250C087 FERRITE CORE EPCOS - TDK Electronics	3,768	-	запрос цен	Техническая	Box	ER11/2.5/6	Active	ER	ER 11 x 5	N87	-	-	-	Gapped	-	2200	1.1	14.1	12.4	10.3	174	Uncoated	0.098 (2.50mm)
B65803J0160A087 FERRITE CORE EPCOS - TDK Electronics	2,730	-	запрос цен	Техническая	Box	-	Not For New Designs	RM	RM 4	N87	-	-	-	-	-	2200	1.7	22	13	11.3	286	Uncoated	0.413 (10.50mm)
B66421G0000X192 FERRITE CORE EPCOS - TDK Electronics	3,029	-	запрос цен	Техническая	Box	EFD25/13/9	Active	EFD	EFD 25 x 13 x 9	N92	-	-	-	-	-	1500	0.98	57	58	57	3310	Uncoated	0.492 (12.50mm)
B65839A0040A033 FERRITE CORE EPCOS - TDK Electronics	2,455	-	запрос цен	Техническая	Box	EP7	Active	EP	EP 7	M33	-	-	-	Gapped	-	750	1.52	15.7	10.3	8.5	162	Uncoated	0.148 (3.75mm)
B66337G0100X127 FERRITE CORE EC N27 1PC EPCOS - TDK Electronics	3,911	-	запрос цен	Техническая	Box	B66337	Not For New Designs	EC	EC 35 x 17 x 10	N27	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.687 (17.45mm)
B65931J0000X022 FERRITE CORES EPCOS - TDK Electronics	2,846	-	запрос цен		Box	PS5.6/1.7	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B65859A0000R057 FERRITE CORE EPX 2UH T57 2PCS EPCOS - TDK Electronics	2,551	-	запрос цен	Техническая	Box	EPX10	Active	EPX	EPX 10	T57	-	2 µH	-20%, +30%	Ungapped	2170	4000	1.37	21.7	15.9	13.2	345	Uncoated	0.205 (5.20mm)
B66319G0000X135 FERRITE CORE EPCOS - TDK Electronics	2,904	-	запрос цен	Техническая	Box	E30/15/7	Active	E	E 30 x 15 x 7	T35	-	-	-	-	-	6000	1.12	67	60	49	4000	Uncoated	0.598 (15.20mm)
B65517W0000R087 FERRITE CORE EPCOS - TDK Electronics	2,864	-	запрос цен	Техническая	Box	P9/5	Active	-	P 9 x 5	N87	0.366 (9.30mm)	-	-	-	-	2200	1.13	13.4	11.9	9.3	159	Uncoated	0.106 (2.70mm)
B66421U0090A197 FERRITE CORE EPCOS - TDK Electronics	3,607	-	запрос цен	Техническая	Box	EFD25/13/9	Active	EFD	EFD 25 x 13 x 9	N97	-	-	-	Gapped	-	2300	0.98	57	58	57	3310	Uncoated	0.492 (12.50mm)
B65523J0000Y038 FERRITE CORE ER 4.5UH T38 2PCS EPCOS - TDK Electronics	3,229	-	запрос цен	Техническая	Box	ER9.5	Active	ER	ER 9.5 x 5	T38	-	4.5 µH	-30%, +40%	Ungapped	5680	10000	1.54	13.6	8.81	-	120	Uncoated	0.098 (2.50mm)
B65855A0000Y038 FERRITE CORE EP 2UH T38 2PCS EPCOS - TDK Electronics	3,018	-	запрос цен	Техническая	Box	EP5	Active	EP	EP 5	T38	-	2 µH	-30%, +40%	Ungapped	5000	2300	3.14	9.73	3.09	2.3	30	Uncoated	0.112 (2.85mm)
B66408G0000X187 FERRITE CORE EV N87 1PC EPCOS - TDK Electronics	2,939	-	запрос цен	Техническая	Box	EV25/13/13	Active	EV	EV 25 x 13 x 13	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.504 (12.80mm)
B66281G0000X192 FERRITE CORE ELP N92 1PC EPCOS - TDK Electronics	3,677	-	запрос цен	Техническая	Box	ELP14/3.5/5	Active	ELP	ELP 14 x 3.5 x 5	N92	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.138 (3.50mm)
B65525J0140A087 FERRITE CORE EPCOS - TDK Electronics	2,780	-	запрос цен	Техническая	Box	ER11/2.5/6	Active	ER	ER 11 x 5	N87	-	-	-	Gapped	-	2200	1.1	14.1	12.4	10.3	174	Uncoated	0.098 (2.50mm)
B65935D0000X033 FERRITE CORE EPCOS - TDK Electronics	2,868	-	запрос цен		Box	PS9.4/3.5	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B64290A0618X087 FERRITE CORE TOROID 2.36UH N87 EPCOS - TDK Electronics	2,989	-	запрос цен	Техническая	Box	T25.3/14.8/15	Active	Toroid	R 25.3 x 14.8 x 10	N87	0.996 (25.30mm)	2.36 µH	±25%	Ungapped	-	2200	1.17	60.07	51.26	-	3079	Uncoated	0.394 (10.00mm)
B64290L0719X065 FERRITE CORE TOROID 3.93UH T65 EPCOS - TDK Electronics	2,787	-	запрос цен	Техническая	Box	TX22/14/7.9	Active	Toroid	-	T65	0.917 (23.30mm)	3.93 µH	±30%	Ungapped	-	5200	1.66	54.2	32.6	-	1763	Epoxy	0.354 (9.00mm)
B65961C0000X033 FERRITE CORE EPCOS - TDK Electronics	3,190	-	запрос цен		Box	PCH11/2.8	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B66283U0160J187 FERRITE CORE EPCOS - TDK Electronics	3,811	-	запрос цен		Box	ELP18/4/10	Active	-	-	-	-	-	-	Gapped	-	-	-	-	-	-	-	-	-
