Производитель Часть #	Доступность	Цена	Количество	Техническая	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B66361G0000X195 FERRITE CORES EPCOS - TDK Electronics	3,189	-	запрос цен	Техническая	Tape & Reel (TR)	ETD34/17/11	Active	ETD	ETD 34/17/11	N95	-	-	-20%, +30%	Ungapped	2170	-	0.81	78.6	97.1	91.6	7630	Uncoated	0.689 (17.50mm)
B65513J0200D097 FERRITE CORE EPCOS - TDK Electronics	2,233	-	запрос цен		Box	ER14.5	Active	ER	ER 14.5 x 6	N97	-	-	-	Gapped	-	2300	1.08	19	17.6	17.3	334	Uncoated	0.116 (2.95mm)
B66361G2500X187 FERRITE CORE EPCOS - TDK Electronics	3,595	-	запрос цен	Техническая	Box	ETD34/17/11	Active	ETD	ETD 34 x 17 x 11	N87	-	-	-	Gapped	-	2200	0.81	78.6	97.1	91.6	7630	Uncoated	0.689 (17.50mm)
B65525J0250B045 FERRITE CORE EPCOS - TDK Electronics	3,276	-	запрос цен	Техническая	Box	ER11/2.5/6	Active	ER	ER 11 x 5	N45	-	-	-	Gapped	-	3800	1.1	14.1	12.4	10.3	174	Uncoated	0.098 (2.50mm)
B65525J0400E045 FERRITE CORE EPCOS - TDK Electronics	3,598	-	запрос цен	Техническая	Box	ER11/2.5/6	Active	ER	ER 11 x 5	N45	-	-	-	Gapped	-	3800	1.1	14.1	12.4	10.3	174	Uncoated	0.098 (2.50mm)
B65843A0100A057 FERRITE CORE EP 100NH T57 2PCS EPCOS - TDK Electronics	2,577	-	запрос цен	Техническая	Box	EP13	Active	EP	EP 13	T57	-	100 nH	±3%	Gapped	99	4000	1.24	24.2	19.5	14.9	472	Uncoated	0.256 (6.50mm)
B65843A0125A057 FERRITE CORE EPCOS - TDK Electronics	2,878	-	запрос цен	Техническая	Box	EP13	Active	EP	EP 13	T57	-	-	-	Gapped	-	4000	1.24	24.2	19.5	14.9	472	Uncoated	0.256 (6.50mm)
B65843A0160B057 FERRITE CORE EP 160NH T57 2PCS EPCOS - TDK Electronics	2,659	-	запрос цен	Техническая	Box	EP13	Active	EP	EP 13	T57	-	160 nH	±4%	Gapped	158	4000	1.24	24.2	19.5	14.9	472	Uncoated	0.256 (6.50mm)
B65843A0200B057 FERRITE CORE EP 200NH T57 2PCS EPCOS - TDK Electronics	2,663	-	запрос цен	Техническая	Box	EP13	Active	EP	EP 13	T57	-	200 nH	±4%	Gapped	198	4000	1.24	24.2	19.5	14.9	472	Uncoated	0.256 (6.50mm)
B65513J0000R092 FERRITE CORE ER 1.1UH N92 2PCS EPCOS - TDK Electronics	3,335	-	запрос цен	Техническая	Box	ER14.5	Active	ER	ER 14.5 x 6	N92	-	1.1 µH	-20%, +30%	Ungapped	970	1500	1.1	19	17.6	-	333	Uncoated	0.116 (2.95mm)
B65843A0000R045 FERRITE CORE EP 2.4UH N45 2PCS EPCOS - TDK Electronics	3,761	-	запрос цен	Техническая	Box	EP13	Active	EP	EP 13	N45	-	2.4 µH	-20%, +30%	Ungapped	2370	3800	1.24	24.2	19.5	14.9	472	Uncoated	0.256 (6.50mm)
B65843A0250J041 FERRITE CORE EPCOS - TDK Electronics	2,766	-	запрос цен	Техническая	Box	EP13	Active	EP	EP 13	N41	-	-	-	Gapped	-	2800	1.24	24.2	19.5	14.9	472	Uncoated	0.256 (6.50mm)
B64290L0719X035 FERRITE CORE TOROID 4UH T35 EPCOS - TDK Electronics	3,635	-	запрос цен	Техническая	Box	TX22/14/7.9	Active	Toroid	-	T35	0.917 (23.30mm)	4 µH	±25%	Ungapped	-	5300	1.66	54.2	32.6	-	1763	Epoxy	0.354 (9.00mm)
B65517D0200A048 FERRITE CORE P 200NH N48 2PCS EPCOS - TDK Electronics	3,014	-	запрос цен	Техническая	Box	P9/5	Active	P (Pot Core)	P 9 x 5	N48	0.366 (9.30mm)	200 nH	±3%	Gapped	200	-	1.25	12.5	10	-	125	Uncoated	0.106 (2.70mm)
B64290A0045X001 FERRITE CORE EPCOS - TDK Electronics	2,166	-	запрос цен	Техническая	Box	T16/9.6/6.3	Active	Toroid	-	-	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	-
B66358G0100X127 FERRITE CORE ETD N27 1PC EPCOS - TDK Electronics	2,958	-	запрос цен	Техническая	Box	ETD29/16/10	Active	ETD	ETD 29 x 16 x 10	N27	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.630 (16.00mm)
B66358G1000X127 FERRITE CORE ETD N27 1PC EPCOS - TDK Electronics	2,215	-	запрос цен	Техническая	Box	ETD29/16/10	Active	ETD	ETD 29 x 16 x 10	N27	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.630 (16.00mm)
B66229G0500X127 FERRITE CORE E N27 1PC EPCOS - TDK Electronics	2,202	-	запрос цен	Техническая	Box	E32/16/9	Active	E	E 32 x 16 x 9	N27	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.646 (16.40mm)
B66358G1000X197 FERRITE CORE EPCOS - TDK Electronics	2,672	-	запрос цен	Техническая	Box	ETD29/16/10	Active	ETD	ETD 29 x 16 x 10	N97	-	-	-	Gapped	-	2300	0.93	70.4	76	71	5350	Uncoated	0.630 (16.00mm)
B65513J0000Y038 FERRITE CORE EPCOS - TDK Electronics	3,827	-	запрос цен	Техническая	Box	ER14.5	Active	-	-	-	-	6.6 µH	-30%, +40%	Ungapped	-	-	-	-	-	-	-	-	-
