Производитель Часть #	Доступность	Цена	Количество	Техническая	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B66285G0000X187 FERRITE CORE ELP N87 1PC EPCOS - TDK Electronics	2,662	-	запрос цен	Техническая	Box	ELP22/6/16	Active	ELP	ELP 22 x 6 x 16	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
B64290L0632X038 FERRITE CORE TOROID 9.74UH T38 EPCOS - TDK Electronics	3,985	-	запрос цен	Техническая	Box	TX20/10/7	Active	Toroid	-	T38	0.835 (21.20mm)	9.74 µH	±30%	Ungapped	-	10000	1.3	43.55	33.63	-	1465	Epoxy	0.319 (8.10mm)
B64290L0618X830 FERRITE CORE TOROID 4620NH N30 EPCOS - TDK Electronics	3,939	-	запрос цен	Техническая	Bulk	TX25.3/14.8/10	Active	Toroid	-	N30	1.047 (26.60mm)	4.62 µH	±25%	Ungapped	-	4300	1.17	60.07	51.26	-	3079	Epoxy	0.433 (11.00mm)
B66358G0000X187 FERRITE CORE ETD N87 1PC EPCOS - TDK Electronics	3,739	-	запрос цен	Техническая	Box	ETD29/16/10	Active	ETD	ETD 29 x 16 x 10	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.630 (16.00mm)
B66283K0000X187 FERRITE CORE I N87 EPCOS - TDK Electronics	2,878	-	запрос цен	Техническая	Tray	I18/2/10	Active	I	I 18 x 2 x 10	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.079 (2.00mm)
4078375111 78 ROD Fair-Rite Products Corp.	3,171	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	78	0.372 (9.45mm)	-	-	Ungapped	-	2300	-	-	-	-	-	Uncoated	-
PQ20/16-3C95 FERRITE CORE 2PC SET Ferroxcube	3,223	-	запрос цен	Техническая	Bulk	-	Active	PQ	PQ 20 x 16	3C95	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.638 (16.20mm)
TX22/14/13-3E27 CORES Ferroxcube	2,603	-	запрос цен	Техническая	Bulk	-	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Epoxy	0.551 (14.00mm)
PLT30/20/3-3C95 FERRITE CORE Ferroxcube	3,346	-	запрос цен	Техническая	Bulk	-	Active	PLT	PLT 30 x 20 x 3	3C95	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.106 (2.70mm)
E42/21/15-3C92 FERRITE CORE Ferroxcube	2,921	-	запрос цен	Техническая	Bulk	-	Active	E	E 42 x 21 x 15	3C92	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.827 (21.00mm)
B66358G0200X187 FERRITE CORE ETD N87 1PC EPCOS - TDK Electronics	2,567	-	запрос цен	Техническая	Box	ETD29/16/10	Active	ETD	ETD 29 x 16 x 10	N87	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.630 (16.00mm)
EQ25-3C95 FERRITE CORE Ferroxcube	2,073	-	запрос цен	Техническая	Bulk	-	Active	EQ	EQ 25	3C95	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.315 (8.00mm)
E41/17/12-3C94 FERRITE CORE Ferroxcube	2,663	-	запрос цен	Техническая	Bulk	-	Active	E	E 41 x 17 x 12	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.654 (16.60mm)
TX25/15/10-3E27 FERRITE CORES ROUND Ferroxcube	3,096	-	запрос цен	Техническая	Bulk	-	Active	Toroid	TX 25 x 15 x 10	3E27	1.007 (25.95mm)	-	±25%	Ungapped	5500	-	1.23	60.2	48.9	-	2944	Epoxy	0.429 (10.90mm)
TX29/19/7.6-3E27 FERRITE CORES ROUND Ferroxcube	3,492	-	запрос цен	Техническая	Bulk	-	Active	Toroid	TX 29 x 19 x 7.6	3E27	1.179 (29.95mm)	-	-	-	-	-	-	-	-	-	-	Epoxy	0.329 (8.35mm)
B66281K0000X149 FERRITE CORE I N49 EPCOS - TDK Electronics	2,172	-	запрос цен	Техническая	Bag	I14/1.5/5	Active	I	I 14 x 1.5 x 5	N49	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.059 (1.50mm)
EFD15/8/5-3F36-S FERRITE CORE 2PC SET Ferroxcube	2,385	-	запрос цен	Техническая	Bulk	-	Active	EFD	EFD 15 x 8 x 5	3F36	-	-	±25%	Ungapped	1170	-	2.27	34	15	12.2	510	Uncoated	0.295 (7.50mm)
B64290L0719X038 FERRITE CORE TOROID 7.57UH T38 EPCOS - TDK Electronics	3,408	-	запрос цен	Техническая	Box	TX22/14/7.9	Active	Toroid	-	T38	0.917 (23.30mm)	7.57 µH	±30%	Ungapped	-	10000	1.66	54.2	32.6	-	1763	Epoxy	0.354 (9.00mm)
PLT32/20/3.2/R-3C95 FERRITE CORE Ferroxcube	3,886	-	запрос цен	Техническая	Bulk	-	Active	PLT	PLT 32 x 20 x 3.2	3C95	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.125 (3.18mm)
4077375211 77 SOLID ROD Fair-Rite Products Corp.	3,206	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	77	0.372 (9.45mm)	-	-	Ungapped	29	2000	-	25	7.07	-	-	Uncoated	-
