Производитель Часть #	Доступность	Цена	Количество	Техническая	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
3061990841 61 ROD Fair-Rite Products Corp.	3,725	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	61	0.059 (1.50mm)	-	-	Ungapped	35	125	-	-	1.77	-	-	Uncoated	-
3067990841 67 ROD Fair-Rite Products Corp.	3,709	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	67	0.059 (1.50mm)	-	-	Ungapped	22	40	-	-	1.77	-	-	Uncoated	-
B62152A0008X030 FERRITE CORE 2 HOLE 3.1UH N30 EPCOS - TDK Electronics	3,368	-	запрос цен	Техническая	Box	MHB2-2.5/3.6/2.1	Active	Multi-Hole (2)	-	N30	-	3.1 µH	±30%	Ungapped	-	4300	1.78	3.7	2.1	-	7.8	Uncoated	0.098 (2.50mm)
E13/6/6-3C94 FERRITE CORE Ferroxcube	386	-	запрос цен	Техническая	Bulk	-	Active	E	E 13 x 6 x 6	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
B64290L0044X027 FERRITE CORE TOROID 1.02UH N27 EPCOS - TDK Electronics	3,712	-	запрос цен	Техническая	Box	TX12.5/7.5/5	Active	Toroid	-	N27	0.535 (13.60mm)	1.02 µH	±25%	Ungapped	-	2000	2.46	30.09	12.23	-	368	Epoxy	0.234 (5.95mm)
B64290L0644X830 FERRITE CORE TOROID 2.03UH N30 EPCOS - TDK Electronics	2,457	-	запрос цен	Техническая	Box	TX13.3/8.3/5	Active	Toroid	-	N30	0.567 (14.40mm)	2.03 µH	±25%	Ungapped	-	4300	2.67	32.7	12.27	-	401	Epoxy	0.234 (5.95mm)
B66305G0000X130 FERRITE CORE E N30 1PC EPCOS - TDK Electronics	3,148	-	запрос цен	Техническая	Box	E13/7/4	Active	E	E 13 x 7 x 4	N30	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.256 (6.50mm)
B62152P0008X030 FERRITE CORE 2 HOLE 3.1UH N30 EPCOS - TDK Electronics	2,370	-	запрос цен		Box	MHB2/P-3.6/2.1/2.5	Active	Multi-Hole (2)	-	N30	-	3.1 µH	±30%	Ungapped	-	4300	1.78	3.7	2.1	-	7.8	Parylene	0.100 (2.54mm)
B64290L0658X830 FERRITE CORE TOROID 1.9UH N30 EPCOS - TDK Electronics	2,404	-	запрос цен	Техническая	Box	TX14/9/5	Active	Toroid	-	N30	0.594 (15.10mm)	1.9 µH	±25%	Ungapped	-	4300	2.84	34.98	12.3	-	430	Epoxy	0.236 (6.00mm)
E20/10/5-3C94 FERRITE CORE Ferroxcube	2,911	-	запрос цен	Техническая	Bulk	-	Active	E	E 20 x 10 x 5	3C94	-	-	-	-	-	-	-	-	-	-	-	Uncoated	0.394 (10.00mm)
B64290L0044X049 FERRITE CORE TOROID 660NH N49 EPCOS - TDK Electronics	3,341	-	запрос цен	Техническая	Box	TX12.5/7.5/5	Active	Toroid	-	N49	0.535 (13.60mm)	660 nH	±25%	Ungapped	-	1300	2.46	30.09	12.23	-	368	Epoxy	0.234 (5.95mm)
B66300G0000X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	3,975	-	запрос цен	Техническая	Box	E6.3	Active	E	E 6 x 3	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.114 (2.90mm)
3067990861 67 ROD Fair-Rite Products Corp.	3,851	-	запрос цен	Техническая	Bulk	-	Active	ROD	-	67	0.098 (2.50mm)	-	-	Ungapped	19	40	-	-	4.91	-	-	Uncoated	-
B64290L0062X065 FERRITE CORE TOROID 2.05UH T65 EPCOS - TDK Electronics	3,330	-	запрос цен	Техническая	Box	TX9.5/4.8/3.2	Active	Toroid	-	T65	0.413 (10.50mm)	2.05 µH	±30%	Ungapped	-	4600	2.85	20.72	7.28	-	151	Epoxy	0.161 (4.10mm)
TX14/9/5-3E27 FERRITE CORES ROUND Ferroxcube	3,097	-	запрос цен	Техническая	Bulk	-	Active	Toroid	TX 14 x 9 x 5	3E27	0.561 (14.25mm)	-	-	-	-	-	-	-	-	-	-	Epoxy	0.207 (5.25mm)
7878400121 78 PLANAR EI CORE SET Fair-Rite Products Corp.	3,496	-	запрос цен	Техническая	Bulk	-	Active	E	-	78	-	-	±25%	Ungapped	-	2300	109	16.6	15.2	15	252	Uncoated	-
TX13/7.9/6.4-3E10-M FERRITE CORES ROUND Ferroxcube	2,189	-	запрос цен	Техническая	Bulk	-	Active	Toroid	TX 13 x 7.9 x 6.4	-	0.526 (13.35mm)	-	±30%	Ungapped	10000	-	2.21	31.2	14.1	-	442	Epoxy	0.275 (7.00mm)
TX14/9/5-3E12 FERRITE CORES ROUND Ferroxcube	2,455	-	запрос цен	Техническая	Bulk	-	Active	Toroid	TX 14 x 9 x 5	-	0.561 (14.25mm)	-	±30%	Ungapped	-	-	2.84	35	12.3	-	430	Epoxy	0.207 (5.25mm)
TX10/6/4-3C94 FERRITE CORES ROUND Ferroxcube	3,709	-	запрос цен	Техническая	Bulk	-	Active	Toroid	-	3C94	-	-	-	Ungapped	-	-	3.07	24.1	7.8	-	3.07	Epoxy	0.167 (4.25mm)
B66307G0000X130 FERRITE CORE E N30 1PC EPCOS - TDK Electronics	3,182	-	запрос цен	Техническая	Box	E16/8/5	Active	E	E 16 x 8 x 5	N30	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.323 (8.20mm)
