+86 15815556552ёмкость алюминиевого электролиза пластыря
| Фото | Производитель Часть # | Доступность | Цена | Количество | Техническая | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEA-GA1A470HCAP ALUM 47UF 20% 10V RADIAL |
1,225 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | GA-A | Active | 47 µF | ±20% | 10 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 65 mA @ 120 Hz | 100.8 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.276 (7.00mm) | - | Through Hole |
|
EEA-GA1H150BCAP ALUM 15UF 20% 50V RADIAL |
1,045 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | GA-A | Active | 15 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 55 mA @ 120 Hz | 85.25 mA @ 100 kHz | - | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.276 (7.00mm) | - | Through Hole |
|
EEE-1VA100ARCAP ALUM 10UF 20% 35V SMD |
2,520 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | S | Not For New Designs | 10 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 30 mA @ 120 Hz | 51 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.213 (5.40mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
|
EEE-1EA100ARCAP ALUM 10UF 20% 25V SMD |
1,996 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | S | Not For New Designs | 10 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 28 mA @ 120 Hz | 47.6 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.213 (5.40mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
ECE-A1HN3R3UBCAP ALUM 3.3UF 20% 50V RADIAL |
1,995 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | SU | Active | 3.3 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | 25 mA @ 120 Hz | 42.5 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
|
ECE-A1VN4R7UBCAP ALUM 4.7UF 20% 35V RADIAL |
1,986 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | SU | Active | 4.7 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | - | General Purpose | - | - | - | 0.197 (5.00mm) | 0.197 Dia (5.00mm) | 0.472 (12.00mm) | - | Through Hole |
|
EEU-FR1C101BCAP ALUM 100UF 20% 16V RADIAL |
1,634 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FR-A | Active | 100 µF | ±20% | 16 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 196 mA @ 120 Hz | 280 mA @ 100 kHz | 300 mOhms | 0.197 (5.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
EEU-FC1E470BCAP ALUM 47UF 20% 25V RADIAL |
1,182 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FC | Active | 47 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 113.8 mA @ 120 Hz | 175 mA @ 100 kHz | 800 mOhms | 0.197 (5.00mm) | 0.197 Dia (5.00mm) | 0.571 (14.50mm) | - | Through Hole |
|
EEE-HBJ470UARCAP ALUM 47UF 20% 6.3V SMD |
1,876 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HB | Active | 47 µF | ±20% | 6.3 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 26 mA @ 120 Hz | 44.2 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.228 (5.80mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
EEE-FN1A100RCAP ALUM 10UF 20% 10V SMD |
2,576 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 10 µF | ±20% | 10 V | 1.35Ohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 58.5 mA @ 120 Hz | 90 mA @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EEE-FN0J220RCAP ALUM 22UF 20% 6.3V SMD |
1,927 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FN | Active | 22 µF | ±20% | 6.3 V | 1.35Ohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 58.5 mA @ 120 Hz | 90 mA @ 100 kHz | - | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
EEU-FS1A331BCAP ALUM 330UF 20% 10V RADIAL |
1,518 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FS-A | Active | 330 µF | ±20% | 10 V | - | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 318.5 mA @ 120 Hz | 455 mA @ 100 kHz | 130 mOhms | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.500 (12.70mm) | - | Through Hole |
|
EEE-HA1V100ARCAP ALUM 10UF 20% 35V SMD |
1,950 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HA | Not For New Designs | 10 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 30 mA @ 120 Hz | 51 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.213 (5.40mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
EEE-FC0J680PCAP ALUM 68UF 20% 6.3V SMD |
1,892 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | FC | Not For New Designs | 68 µF | ±20% | 6.3 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 105 mA @ 120 Hz | 140 mA @ 100 kHz | 1 Ohms | - | 0.248 Dia (6.30mm) | 0.213 (5.40mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
ECA-1HEN100BCAP ALUM 10UF 20% 50V RADIAL |
1,266 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | GA-A (Bi-polar) | Active | 10 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Bi-Polar | - | General Purpose | 50 mA @ 120 Hz | 85 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.248 Dia (6.30mm) | 0.480 (12.20mm) | - | Through Hole |
|
|
EEE-HB1HR33ARCAP ALUM 0.33UF 20% 50V SMD |
3,084 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HB | Obsolete | 0.33 µF | ±20% | 50 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 3 mA @ 120 Hz | 5.1 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.228 (5.80mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EEE-HB1HR22ARCAP ALUM 0.22UF 20% 50V SMD |
3,062 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HB | Obsolete | 0.22 µF | ±20% | 50 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 2 mA @ 120 Hz | 3.4 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.228 (5.80mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EEA-GA1E680HCAP ALUM 68UF 20% 25V RADIAL |
1,931 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | GA-A | Active | 68 µF | ±20% | 25 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 100 mA @ 120 Hz | 155 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.315 Dia (8.00mm) | 0.276 (7.00mm) | - | Through Hole |
|
EEU-FM1E221BCAP ALUM 220UF 20% 25V RADIAL |
2,449 | - |
|
Техническая |
Cut Tape (CT),Tape & Box (TB) | FM-A | Active | 220 µF | ±20% | 25 V | - | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 665 mA @ 120 Hz | 950 mA @ 100 kHz | 56 mOhms | 0.197 (5.00mm) | 0.315 Dia (8.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
|
EEE-HB1C220ARCAP ALUM 22UF 20% 16V SMD |
1,860 | - |
|
Техническая |
Tape & Reel (TR),Cut Tape (CT) | HB | Active | 22 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 39 mA @ 120 Hz | 66.3 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.228 (5.80mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
